Telefunken TF-PS2203 [3/18] Instruction manual

Instruction manual

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended to read

this manual carefully before connecting, operating and/or adjusting the product and keep

the manual for reference in future.

Description

Top panel

1. DISPLAY

2. PAIR INDICATOR

3. CHARGE INDICATOR

4. P-MODE/M. BUTTON

5. /TUN.- BUTTON

6. LIGHT BUTTON

7. FOLDER/10/M. - BUTTON

8. PLAY/PAUSE/PAIR/SCAN

BUTTON

9. /TUN.+ BUTTON

10. POWER SWITCH

11. FUNCTION BUTTON

12. FOLDER/10/M. + BUTTON

13. VOLUME KNOB

14. GUITAR VOLUME KNOB

15. TREBLE KNOB

16. BASS KNOB

17. MIC ECHO KNOB

18. MIC VOLUME KNOB

19. USB PORT 2

20. 6.3MM MIC JACK

21. 6.3MM GUITAR JACK

22. 3.5MM AUX IN JACK

23. USB PORT 1

24. HANDLE

Front and back panels

25. LED LIGHT

26. TWEETER

27. SPEAKER

28. SPEAKER GRILL

29. AC SOCKET

30. VENTILATION HOLES
