02 TV Installation

Mounting the TV on a wall

If you mount this TV on a wall, follow the instructions exactly as set out by the manufacturer. Unless

it is correctly mounted, the TV may slide or fall and cause serious injury to a child or adult and

serious damage to the TV.

For models providing wall mount adapters, install them as shown in the figure below before installing the wall

mount kit.

• Refer to the installation manual included with the Samsung wall mount kit.

Wall mount

bracket

Wall mount

bracket

Wall mount Adapter

• Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you

choose to install the wall mount on your own.

• You can install your wall mount on a solid wall perpendicular to the floor. Before attaching the wall mount

to surfaces other than plaster board, contact your nearest dealer for additional information. If you install

the TV on a ceiling or slanted wall, it may fall and result in severe personal injury.

• Standard dimensions for wall mount kits are shown in the table on the next page.

• If you are installing a third-party wall mount, note that the length of the screws you can use to attach the

TV to the wall mount is shown in column C in the table on the next page.

• When installing a wall mount kit, we recommend you fasten all four VESA screws.

• If you want to install a wall mount kit that attaches to the wall using two top screws only, be sure to use a

Samsung wall mount kit that supports this type of installation. (You may not be able to purchase this type

of wall mount kit, depending on the geographical region.)
