Thermex TitaniumHeat 100 V [24/52] Manufacturer s warranty

Transportation and storage of electric water heaters

Electric water heaters shall be transported and stored in accordance with the handling symbols

shown on the package:

1. 2. 3. 4.

1. The need to protect the cargo from moisture;

2. Frailty of the cargo, condition of careful handling;

3. Recommended temperature range for cargo storage: from +10°С to +20°С;

4. Correct vertical position of the cargo;

Manufacturer's Warranty

The manufacturer sets the warranty period for the water heater for 1 year, while the warranty terms for

the constituent parts and components are as follows:

for water-containing reservoir (internal tank) – 5 years;

for other components (heating element, thermostat, indicator lamps, gaskets, relief valve) – 1 year.

The temperature indicator located on the EWH casing is not an accurate measuring device and is

intended for indicating the process of heating or cooling the water contained in the water heater tank.

The incorrect operation of the temperature indicator is not a reason for replacing the EWH under the

warranty.

The warranty period shall be calculated from the date of sale of the EWH. In the absence or correction

of the date of sale and the store stamp, the warranty period shall be calculated from the date of

release of the EWH. Claims during the warranty period shall be accepted if there is a warranty

certificate with the dealer's marks and the identification plate on the EWH casing.

CAUTION! The failure of the relief valve or power cord is not a malfunction of the EWH itself and shall

not entail the EWH replacement. The responsibility for compliance with the installation and

connection rules rests with the buyer (in case the buyer performs the connection using their own

resources) or with the installation organization that performed the connection.

When installing and operating the EWH, the customer shall comply with the requirements

ensuring trouble-free operation of the device during the warranty period:

comply with the safety measures and installation, connection, operation, and maintenance rules

set forth herein;

exclude mechanical damage from negligent storage, transportation, and installation;

eliminate the freezing of water in the EWH;

use for heating in the EWH water without mechanical and chemical impurities;

use the EWH with a properly operating relief valve from the EWH supply package.

Frequent triggering

of the thermal switch

The set temperature is close

to the temperature limit

Turn the thermostat knob toward

temperature decrease (–)

The thermostat tube

is covered with scale

Remove the removable flange

from the EWH and carefully

clean the pipe from scale

There is no voltage in the

power supply network

Contact the organization

responsible for the maintenance

of the power supply network

The residual current device

was triggered

Press the reset button of the

residual current device.

Check the voltage.

The powered EWH

does not heat water.

There is no backlight

of control lamps.

Contact the service center

The mains cable is damaged

Disconnect the EWH from the

power supply network, remove

the protective cover, press the

thermal switch button until it is

secure, install the cover and

switch on the power supply (Fig. 3)

The thermoswitch was

triggered or is not switched on

The abovementioned malfunctions are not defects of the EWH and shall be eliminated by the

customer themselves or by a specialized organization at the customer's expense.

Where impossible to eliminate the malfunction using the above recommendations or in case of any

other problems, contact the service center specified in the user manual.

Fig. 3

Push

EN EN
