51 & 52 Series II

Using the Thermometer

1. Plug the thermocouple(s) into the input connector(s).

2. Press

A to turn on the thermometer.

After 1 second the thermometer displays the first reading.

If no thermocouple is plugged into the selected input or the

thermocouple is "open," the display shows "- - - -"

Changing Setup Options

Use Setup to change the thermocouple type, offset, sleep

mode, and line frequency settings.

The thermometer stores the settings in its memory. Setup

settings reset only when the batteries are removed for

more than 2 minutes.

Entering or Exiting Setup

When the thermometer is in Setup mode, the display

shows s.

• Press

D to start or exit Setup.

Setup Options

Option

Item Settings

Thermocouple

Type

TYPE J, K, T, or E

Offset O T1 or T2 (Model 52)

Sleep Mode SLP on (sleep mode on)

or 0FF (sleep mode

off)

Line Frequency Li ne 50 H (50 Hz)

or 60 H (60 Hz)
