platinum
ENG
Thank you for buying filters SVEN!
Filters are produced specially for connecting electrical devices to power supply and for protecting them from
highvoltage spikes and highfrequency interference.
FEATURES
z
Power supply LED indicator
z
Six universal sockets with ground contact
z
Five switches for independent socket commutation
z
Improved RFI/EMI noise filter
z
Automatic Recoverable Circuit Breaker
z
The fireproof and shockresistant case from ABSplastic
z
Wall attaching
PRECAUTIONS
z
Do not connect filter to power 380 V
z
Connect the filter only to a threewire power line (with a separate line of grounding)
z
Do not allow the device contact with thinners
z
Do not put the device in damp circumstances, prevent from moisture, dust and high temperatures
z
Do not use the filter at the high humidity
z
Do not connect simultaneously devices with total power more then 2,2 kW
z
Do not open and repair the device independently
CONNECTION
1. Connect all the necessary equipment to the filter sockets.
2. Connect filter to power supply 220230 V. Two lightemitting diodes of presence of an entrance voltage will light up.
3. Switch on the tumbler opposite the socket which is necessary to connect. Indicator in tumbler switches at the
connection.
4. For repeated inclusion of the filter after operation of protection on an overload it is necessary to press the but
ton on an automatic fuse
5. At occurrence on an input of the filter of highvoltage impulses with energy above admissible elements of the
filter (varistors) can fail, having provided thus protection of the connected equipment. The further operation of the
filter thus is not supposed, elements of the filter are a subject to replacement.
SPECIFICATIONS
Note. Given specification may not serve the bases for claims.
Durability — 2 years.
Power rating, V 220
Load power rating, kW 2.2
Working frequency, Hz 50
Thermal circuit breaker Recoverable, 10 А
Surge protector phaseneutral/phaseground/neutralground
RFI/EMI noise filter 20–100
Maximum energy dissipation, J 3 х 150
Maximum spike current, А 5 000
Output sockets (EURO) 5
Package size, mm 270 х 120 х 50
OPERATION MANUAL
