![Epson Stylus 1000 [11/123] Features](/views2/1053151/page11/bgb.png)
Your new Epson printer is a
48-nozzle
ink jet printer, ideal for
quiet, high-speed printing.
Features
Your printer offers the following features:
*
*
*
*
*
*
*
High print quality. Epson’s new ink jet technology delivers
crisp
360
x
360
dot-per-inch
(dpi)
text and graphics.
Flexible paper handling. Use the built-in paper feeder to
load up to
100
sheets automatically. You can also insert
envelopes or single pages manually without removing the
paper supply.
Wide range of paper size with
136
printable columns. You
can print on paper up to A3 size:
297
mm x
420
mm
(11.7
inches x
16.5
inches) using the paper feeder. You can
manually insert paper up to
420
mm x
420
mm
(16.5
inches
x
16.5
inches).
Quiet printing. Ink jet technology helps maintain a quiet
working environment.
Epson
ESC
/
P
2?’
This enhanced printer control language
adds scalable fonts and improved graphics capability.
Compatibility. Supports the Epson
ESCI
I@
commands
widely used in software written for other Epson printers.
Convenience. Drop-in ink cartridge prints up to
700
pages.
(at
1000
characters per page, using the Roman font)
