CHAPTER 4: NEW OR ENHANCED ESC/P2 COMMANDS

4.1 ESC/P 2 Print Raster Graphic Command

Format:

ASCII ESC

c v h m n

Hex 1B 2E c v h m n

Dec 27 101 c v h m n

Parameter range:

c = 0, 1, 2 Print Mode: 0 - uncompressed raster,

1 - compressed raster - RLE,

2 - compressed raster - TIFF, &

3 - compressed raster - Delta Row

v = 5, 10, 20 Print density in the vertical direction, v/3600 DPI

h = 5, 10, 20 Print density in the horizontal direction, v/3600 DPI

m = 1, 8, 24 Raster band height in dots. See Table below.

0 ≤ n

≤ 255 n

and n

define the number of dots in the horizontal direction.

0 ≤ n

≤ 127 The MSB of n

is masked

0 ≤ d ≤255 Data

Series Two and Three Printers

II. Stylus Pro, Stylus Pro XL, Stylus COLOR II, Stylus COLOR IIs, Stylus 820,

Stylus 1500

III. Stylus Pro XL +, Stylus COLOR 200, and Stylus COLOR 500

Series Two and Three ESC . Parameter Interaction

Print Mode Command Parameter Micro

V H v h m Weave

180 x 180 180 180 20 20 1, 8,

N/A

360 x 360 ESC . 0, 1,

2 or 3

360 360 10 10 1, 8,

Available

360x720 720 360 5 10 1 Available

720 x 720 720 720 5 5 1, 8,

Available
