4. FRONT PANEL
a
Infrared remote receptor. Aim at the receptor and then press buttons on the
remote when using remote control.
b
«STAND BY» button. Connect to the AC power; the indicator will turn red
indicating the receiver is in stand by. Press the «STAND BY» button; then the
indicator will turn blue. This indicates that the receiver comes into normal work-
ing state.
c
«CH+» and «CH-» button. When the receiver is receiving normal TV signal,
press the «CH+» or «CH-» button to select programming channel forward or backward. In the menu, press
the «CH+» or "CH-" button to select the items that needs to be adjusted upward or downward.
d
«VOL+» and «VOL-» button. When the receiver is receiving normal TV signal, press the «VOL+» or
«VOL-» button to adjust the volume of the speaker. Press the «VOL+» or «VOL-» button to select the menu
and to adjust the selected items in the menu.
e
«MENU» button. Press the «MENU» button to get into the menu; press the «MENU» again to exit.
f
«MODE» button. Press the «MODE» button continuously, TV/AV/S-Video/YCbCr/YPbPr/PC/SCART sev-
eral program sources will be selected in turn.
5. REMOTE CONTROL
a
«STAND BY»
button: The function is the same as the
power function of «STAND BY» on the receiver button
board.
b
«MUTE»
button: Used for muting the speakers when
this button is pressed. The mute symbol is displayed on
the upper%right corner of the screen; pressed again to
regain the sound and the mute symbol disappears.
c
«0-9»
number button: Used for selecting «0%9» pro%
gram number directly.
d
«MODE»
button: Used for selecting the program sources. The program
sources TV–AV–S%Video–YCbCr–YPbPr–PC–SCART is selected in sequence,
and the corresponding symbol is shown on the nether%right corner of the screen
when press this button. The function is the same as the mode function of «MODE»
on the receiver button board.
e
«MENU»
button: The function is the same as the function of «MENU» on the
receiver button board.
f
«CH+/CH-»
button: Used for increasing or decreasing program channel
number when viewing TV program. Other functions are the same as the func%
tion of the «CH+» and «CH%» on the receiver button board.
g
«VOL+/VOL-»
button: Used for adjusting the volume of the speaker. Other
functions are the same as the function of the «VOL+» and «VOL%»button on the
receiver button board.
h
«DISPLAY»
button: Press this button to display current broadcasting TV
program number, sound system, color system and the sleep time if you have
chosen sleep time on the upper%right corner of the screen.(this function is only
used for TV signal)
i
«SLEEP»
button: Press this button to display the Sleep Time frame, then
press the [VOL+] or [VOL%] button to select the time.
j
«I/II»
button: Used for selecting sound mode directly. Press the button con%
tinuously and the symbols «Mono» % «Stereo» are displayed on the screen of the
upper%right corner in turn. «I» stands for mono sound while «II» stands for stereo.
In case of bilingual broadcast. Press «I/II» firstly to enter «Dual A» mode; press
«I/II» secondly to enter «Dual B» sound mode; press «I/II» thirdly to enter «Mono»
mode.
k
«AUTO»
button: When the input is PC signal, the receiver will adjust the
parameters of selected display format automatically to get the best effect when
pressing this button.
l
«16:9»
button: No «16:9» function for this receiver.
m
«P.SYS»
button: Used for selecting the picture mode in no teletext mode. The
picture mode «Mild» %«Standard»%« Dynamic» %«Memory» is selected in sequence.
n
%
v
Teletext buttons.
23
Eng SVEN STL2000
MUTE
SLEEP
I/II
DISPLAY
HOLD
MENU
CH+
CH–
VOL
–
VOL
+
TIME
TEXT MIX
INDEX
SUBCODE SUBTITLE
SIZE
AUTO P. SYS16:9
STAND BYMODE
1234
56
90
78
RECALL
r
g
e
t
s
p
m
i
d
o
vj
ab
h
c
f
n
u
q
k
l
