7. CONNECTION

Connect a DVD or VHS etc. video devices to this receiver to appreciate a high quality picture.

1). VCD, DVD or Other Video Devices «S-Video» Connection

Connect the «S-Video» input terminal and «Audio Input» terminals of this receiver with «S-video» output terminal and «Audio Output»

terminals of VCD, DVD, VHS or other video devices; press the «MODE» button on the remote control or on the receiver button board to

select «S-Video» to get the program input.

2). VCD, DVD or Other Video Devices «AV» Connection

Connect the «AV» input video and audio terminals of this receiver with «AV» output video and audio terminals of VCD, DVD, VHS or

other video devices; press the «MODE» button on the remote control or on the receiver button board to select «AV» to get the program

input.

3). DVD Component Connection

Connect the «Y, Cb (Pb), Cr(Pr)» DVD component input terminals and «Audio Input» terminals of this receiver with «Y, Cb (Pb), Cr(Pr)»

DVD component output terminals and «Audio Output» terminals of a DVD player; press the «MODE» button on the remote control or on

the receiver button board to select DVD Component «Y, Cb (Pb), Cr(Pr)» to choose the program input.

4). Analog RGB (PC) Connection

Connect the «VGA» analog RGB input terminal of this receiver with «VGA» analog RGB output terminal of a person computer; press

the «MODE» button on the receiver button board or on the remote control to select «PC» to appreciate the program input.

5). SCART Connection

Connect the «SCART AV (RGB)» input terminal of this receiver with signal generator, press the «MODE» button on the receiver button

board or on the remote control to select «SCART» to appreciate the program input.

The displaying resolution of the receiver is 640x480 which supporting PC 640x480 (32bite true color) format and lower format. The

receiver can detect the format of input signals automatically and adjust to the best effect automatically. Employ 640x480 (refresh

frequency 60Hz) or not lower format before connect the PC signals to ensure the receiver works in gear.

When signal is not connected to RGB/S-Video/Video/Y, Cb (Pb), Cr (Pr)/SCART mode, LCD TV will turn into sleeping mode. As sig-

nal is connected or press the «MODE» button on TV, LCD TV would wake up.

The «SCART» mode will be superior to the others, when the «SCART» signal is inputted.

The «SCART» signal does not connect into at the same time with the «AV» signal.
