![Ebara 3TP3-8 FHS M/1,5 PFC [2/2] Applications](/views2/1539181/page2/bg2.png)
APPLICATIONS
Domestic water supply systems (manufactured
accordingly to TIFQ, ACS, WRAS and all the
European certification for domestic drinking water)
Small waterworks
Irrigation and water pumping in general
Water transfering
Pressure boosting of clear water for agriculture,
domestic or industrial use
Adapting old unusable 4" water wells
MAIN FEATURES
Plug & Play - friendly usage
Single-phase 230V input
(power source)
Easy to handle and install
Compact and robust construction
High efficiency pump and motor
Energy saving
Plug in type motor cable:
available with 15, 30, 45 and 60 m lenght
Additional controls may be installed
Soft start
Fully protected:
- Over temperature protection
- Dry-running protection
- Over load protection
- High/low voltage protection
- Phase failure protection
- Surge voltage protection
Your Life, our Quality. Worldwide. 3TP
PERFORMANCE RANGE (according to ISO 9906 Attachment A)
PUMP SPECIFICATION
MOTOR SPECIFICATION
RANGE
3TP
new 3” high speed EBARA pump.
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Model Stage Connection Motor power Capacity Head Dimension [mm]
size [kW] [m
3
/h] [m] Without PFC With PFC
3TP2
4 Rp 1” 0,6 3,3 57,6 894 918
6 Rp 1” 0,9 3,3 81 973 997
9 Rp 1” 1,5 3,3 128 - 1200
3TP3
3 Rp 1” 0,6 4,5 48 870 894
5 Rp 1” 0,9 4,5 77 950 974
8 Rp 1” 1,5 4,5 127 - 1175
3TP5
4 Rp 1”¼ 0,9 7,5 52 946 970
7 Rp 1”¼ 1,5 7,5 90,9 - 1187
Type Three-phase induction motor built in VFD
Voltage [V] 230
Frequency [Hz] 50 / 60
Output [kW] 0,6 - 0,9 - 1,5
Rotation speed [min
-1
] 8400
Capacity (best efficiency point) [m
3
/h] 2 - 3 - 5
Head [m] Max. 147
Maximum temperature of the liquid [°C] 35
Maximum immersion [m] 150
Maximum presence of sand [ppm] 50
Material
Discharge and suction casing ASTM CF8 (SCS13)
Impeller, Interstage casing, Diffuser PPO mod glass fiber reinforced
Shaft AISI 304
