Alpicair ACMI-50HPDC1 [2/10] Be sure that there are no obstructions
![Alpicair ACMI-50HPDC1 [2/10] Be sure that there are no obstructions](/views2/1054195/page2/bg2.png)
пульт дистанционного управления
2
Remote control operation procedure
Name and Function-Remote control
SWING button
When it is pressed, the louvers
start to rotate automatically and
stop when repressed.
TEMP.button
SET TEMP. increases 1
by
pressing button once,and decreases
1
by pressing button once.
At COOL mode operation, SET
TEMP. can be selected from 16
to
30
.
At DRY mode operation, SET TEMP.
can be selected from 16
to 30 .
At HEAT mode operation, SET
TEMP. can be selected from 16
to
30
.
MODE button
press this button to change the
operation mode in order of:
Note:
Cooling only type have no
“ ” mode.
FAN button
Press this button to
change the fan speed of:
“ ” COOL mode
“ ” DRY mode
“ ” FAN mode
“ ” HEAT mode
ON/OFF button
Press this button to turn on
or turn off the unit.
Note:
Be sure that there are no obstructions.
Don’t drop or throw the remote controller.
Don’t place the remote controller directly in the sunlight.
Remote control operation procedure
4
AUTO
ON/OFF
Пульт дистанционного управления
Кнопки на пульте ДУ
Примечание:
• Убедитесь, что между пультом ДУ и кондиционером нет препятствий.
• Не роняйте и не бросайте пульт ДУ.
• Берегите пульт ДУ от прямых солнечных лучей.
Кнопка SWING
При нажатии этой кнопки жалюзи
начинают автоматически вращаться; при
повторном нажатии – останавливаются.
Кнопка MODE
При каждом нажатии этой кнопки
переключается режим работы
кондиционера в следующем порядке:
Примечание:
В системах охлаждения недоступен режим
« »
Remote control operation procedure
Name and Function-Remote control
SWING button
When it is pressed, the louvers
start to rotate automatically and
stop when repressed.
TEMP.button
SET TEMP. increases 1
by
pressing button once,and decreases
1
by pressing button once.
At COOL mode operation, SET
TEMP. can be selected from 16
to
30
.
At DRY mode operation, SET TEMP.
can be selected from 16
to 30 .
At HEAT mode operation, SET
TEMP. can be selected from 16
to
30
.
MODE button
press this button to change the
operation mode in order of:
Note:
Cooling only type have no
“ ” mode.
FAN button
Press this button to
change the fan speed of:
“ ” COOL mode
“ ” DRY mode
“ ” FAN mode
“ ” HEAT mode
ON/OFF button
Press this button to turn on
or turn off the unit.
Note:
Be sure that there are no obstructions.
Don’t drop or throw the remote controller.
Don’t place the remote controller directly in the sunlight.
Remote control operation procedure
4
AUTO
ON/OFF
Remote control operation procedure
Name and Function-Remote control
SWING button
When it is pressed, the louvers
start to rotate automatically and
stop when repressed.
TEMP.button
SET TEMP. increases 1
by
pressing button once,and decreases
1
by pressing button once.
At COOL mode operation, SET
TEMP. can be selected from 16
to
30
.
At DRY mode operation, SET TEMP.
can be selected from 16
to 30 .
At HEAT mode operation, SET
TEMP. can be selected from 16
to
30
.
MODE button
press this button to change the
operation mode in order of:
Note:
Cooling only type have no
“ ” mode.
FAN button
Press this button to
change the fan speed of:
“ ” COOL mode
“ ” DRY mode
“ ” FAN mode
“ ” HEAT mode
ON/OFF button
Press this button to turn on
or turn off the unit.
Note:
Be sure that there are no obstructions.
Don’t drop or throw the remote controller.
Don’t place the remote controller directly in the sunlight.
Remote control operation procedure
4
AUTO
ON/OFF
Кнопка FAN
Этой кнопкой регулируется
частота вращения вентилятора:
Remote control operation procedure
Name and Function-Remote control
SWING button
When it is pressed, the louvers
start to rotate automatically and
stop when repressed.
TEMP.button
SET TEMP. increases 1
by
pressing button once,and decreases
1
by pressing button once.
At COOL mode operation, SET
TEMP. can be selected from 16
to
30
.
At DRY mode operation, SET TEMP.
can be selected from 16
to 30 .
At HEAT mode operation, SET
TEMP. can be selected from 16
to
30
.
MODE button
press this button to change the
operation mode in order of:
Note:
Cooling only type have no
“ ” mode.
FAN button
Press this button to
change the fan speed of:
“ ” COOL mode
“ ” DRY mode
“ ” FAN mode
“ ” HEAT mode
ON/OFF button
Press this button to turn on
or turn off the unit.
Note:
Be sure that there are no obstructions.
Don’t drop or throw the remote controller.
Don’t place the remote controller directly in the sunlight.
Remote control operation procedure
4
AUTO
ON/OFF
Режим COOL (охлаждение)
Режим DRY (осушение)
Режим FAN (вентиляция)
Режим HEAT (отопление)
Кнопка включения ON/OFF
Этой кнопкой включается и
выключается система.
Кнопка TEMP
Настройка температуры. При каждом
нажатии кнопки (+) температура
повышается на 1 ºС, а при каждом
нажатии кнопки (-) - понижается на 1 ºС.
В режиме COOL (охлаждение) можно
установить температуру SET TEMP в
диапазоне от 16 до 30 ºC.
В режиме DRY (осушение) можно
установить температуру SET TEMP в
диапазоне от 16 до 30 ºC.
В режиме HEAT (отопление) можно
установить температуру SET TEMP в
диапазоне от 16 до 30 ºC.
