ENG
User’s Manual
PS-600
PS-650
15
Player mode
Attention! The file system of a micro SD carrier is FAT32. Maximum volume is 32 GB. It is not
recommended to use the micro SD Ultra Speed.
• The system will enter the Player mode automatically when a carrier (USB flash or SD card) is
connected to corresponding ports. Use button o to switch between Play / Pause modes. You can
control tracks by using buttons p (previous track) and n (next track).
The use in the wired mode
• Speaker system can be used as an external device for amplifying any audio source with a 3.5 mm
output mini-jack. Connect a cable mini USB, plug 3.5 mini-jack to the audio input AUX b. Turn the
speakers to the LINE mode – press the MODE button j several times until «LINE» appears on the
display.
Reset
To reset the timbres and memorized radio stations: long press EQ m, on display d will appear
"RES", then press the button o (PLAY/PAUSE).
Connecting an additional speaker
For models PS-600/PS-650 you can connect an additional speaker (Bluetooth mode only):
• Turn both speakers into Bluetooth mode.
• Connect the signal source to one of the speakers via Bluetooth (the second column should be in
search mode).
• On both speakers, press and hold button TWS l. On display d the inscription starts flashing TWS.
• If two speakers are successfully connected between themselves, the inscription TWS will glow
constantly.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value PS-600 Value PS-650
Frequency response, Hz 45 – 22 000 45 – 22 000
Output power (RMS), W 50 (2 × 25) 50 (2 × 25)
Speaker diameter, mm Ø 35 + Ø 110 Ø 35 + Ø 110
Bluetooth supported profiles
HSP, HFP, A2DP,
AVRCP
HSP, HFP, A2DP,
AVRCP
Radius of operation, m until 10 until 10
Battery capacity, mA*h 4 000 (2 pcs) 4 000 (2 pcs)
Power supply, V USB/DC 5V USB/DC 5V
Weight, kg 3 800 3 850
Dimensions, mm 470 × 240 × 240 470 × 240 × 240
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due to
the improvement of SVEN production.
