Epson GT-9600 [63/106] Cresson rev c

Maintenance and Troubleshooting

4-3

CRESSON

Rev. C

A5 size CHAP4.fm

2/16/99 Pass 0

Proof Sign-off:

<tantoname> _______

<leadername> _______

<editorname> _______

Replacing the fluorescent lamp

The luminosity of the fluorescent lamp declines over time. If the

lamp breaks or becomes too dim to operate normally, the scanner

stops working and the

OPERATE

light rapidly flashes red. When

this happens, the lamp assembly must be replaced. For details,

contact your dealer.

Caution:

Never open the scanner case. If you think repairs or adjustments

are necessary, consult your dealer.
