www.ika.com
IKAworldwide // #lookattheblue
www.ika.com
Scope of delivery
> Reaction block
> Electrolysis cells
> Power supply
> IKA Plate (RCT digital) including
PT 1000 Temperature Control
> Cable Set
> Screwdrive
> RS 232 cable PC 1.1
> USB RS 232 converter 4 Ports
> Electrode graphite (16 pcs)
Technical data IKA Screening System
CONTINUOUSLY ADJUSTABLE POWER SUPPLY
Voltage output 0 – 32 V (± 1 mV)
Power output 0 – 10 A
< 1 A (± 0,2 mA )
≥ 1 A (± 1 mA )
Supply voltage 115 or 230 V
(50 Hz / 60 Hz)
FUNCTIONS
Galvanostat Yes
MAGNETIC STIRRER
RPM 0 – 1500 rpm
REACTION CELLS
Number of cells 6 or 8
Usable volumes of
undivided cell 8 ml
Usable volumes of
divided cell (per chamber) 8 ml
Material PTFE
Divided cells Yes (6 System)
Temperierung Yes (RT to 100°C)
Technical data
Industries
Research, Chemicals, Pharmaceuticals, Agrochemistry
IKA-Werke GmbH & Co.KG
Janke & Kunkel-Straße 10, 79219 Staufen, Germany
Phone: +49 7633 831-0, Fax: +49 7633 831-98
eMail: sales@ika.de, Webseite: www.ika.com
201804_Screening System_flyer_10549837_ EN
