IKA RT 15 0003692600 [21/35] Technical data
![IKA RT 15 0003692600 [21/35] Technical data](/views2/1544939/page21/bg15.png)
Technical data
/// Magnetic stirrers with heating function
IKA Plate (RCT digital)
Ident. No. 0025004969
RCT basic
Ident. No. 0003810000 *
Max. stirring quantity (H₂O) 20 l 20 l
Motor rating input / output 16 / 9 W 16 / 9 W
Speed range 0 / 50 – 1.500 rpm 100 – 1.500 rpm
Speed display LCD LED
Max. stirring bar length 80 mm 80 mm
Heat output 600 W 600 W
Heating rate (1 l H
2
O in H15) 7 K / min 6,5 K/min
Temperature range 0 – 310 °C RT – 340 °C
Setting accuracy ± 1 K ± 1 K
Adjustable safety circuit 50 °C – 370 °C (± K) 50 – 370 °C
Connection for ext. temp. sensor DIN 12878 DIN 12878
Control accuracy with sensor
PT1000 = 0.5±K
ETS-D5 = 0.5±K
ETS-D6 = 0.2±K
PT 1000: ± 1 K
ETS-D5: ± 0,5 K
ETS-D6: ± 0,2 K
Set-up plate material aluminium aluminium alloy
Set-up plate dimensions Ø 135 mm Ø 135 mm
Dimensions (W × D × H) 160 × 270 × 85 mm 160 × 270 × 85 mm
Weight 2,4 kg 2,5 kg
Permissible ambient temperature 5 – 40 °C 5 – 40 °C
Permissible relative moisture 80 % 80 %
Protection class acc. to DIN EN 60529 IP 42 IP 42
Voltage 220 – 240 V 220 – 240 V
Frequency 50 / 60 Hz 50 / 60 Hz
Interface USB / RS 232 –
€ 799,00 € 697,00
RET basic
Ident. No. 0003622000
RET control-visc
RET control-visc white
Ident. No. 0005020000*
Ident. No. 0005030000 white*
Max. stirring quantity (H₂O) 20 l 20 l
Motor rating input / output 16 / 9 W 16 / 9 W
Speed range 50 – 1.700 rpm 50 – 1.700 rpm
Speed display LED TFT
Max. stirring bar length 80 mm 80 mm
Heat output 600 W 600 W
Heating rate (1 l H
2
O in H15) 7 K/min 7 K/min
Temperature range RT – 340 °C RT – 340 °C
Setting accuracy ± 1 K ± 0,1 K
Adjustable safety circuit 50 – 360 °C 50 – 370 °C
Connection for ext. temp. sensor DIN 12878 DIN 12878
Control accuracy with sensor
PT 1000: ± 1 K
ETS-D5: ± 0,5 K
ETS-D6: ± 0,2 K
PT 100: ± 0,2 K
Set-up plate material aluminum stainless steel 1,4301 | white ceramic
Set-up plate dimensions Ø 135 mm Ø 135 mm
Dimensions (W × D × H) 160 × 270 × 95 mm 160 × 270 × 85 mm
Weight 2,5 kg 3 kg
Permissible ambient temperature 5 – 40 °C 5 – 40 °C
Permissible relative moisture 80 % 80 %
Protection class acc. to DIN EN 60529 IP 42 IP 42
Voltage 220 – 240 V 220 – 240 V
Frequency 50 / 60 Hz 50 / 60 Hz
Interface – USB / RS 232
€ 996,00 € 1.262,00
€ 1.290,00
TECHNICAL DATA
/// Comparison
TECHNICAL DATA
/// Comparison
* PT 1000.60 included in delivery
* PT 100 included in delivery
40 41
