RH basic
RH basic white
Ident. No. 0005019700
Ident. No. 0005029700
white
RH digital
RH digital white
Ident. No. 0005019800
Ident. No. 0004678000
white
RH basic 2
Ident-No. 0003339000
Max. stirring quantity (H₂O) 15 l 15 l 10 l
Motor rating input / output 15 / 2 W 15 / 2 W 15 / 2 W
Speed range 50 – 2.000 rpm 50 – 2.000 rpm 100 – 2.000 rpm
Speed display Scale LED scale (0 – 6)
Max. stirring bar length 80 mm 80 mm
Heat output 600 W 600 W 400 W
Heating rate (1 l H
2
O in H15) 6 K / min 6 K / min
Temperature range 50 – 320 °C 50 – 320 °C RT – 320 °C
Setting accuracy – | ± 5 K – | ± 5 K
Adjustable safety circuit 50 – 370 °C 50 – 370 °C 400 °C (fixed)
Connection for ext. temp. sensor DIN 12878 DIN 12878
Control accuracy with sensor
ETS-D5: ± 0,5 K
ETS-D6: ± 0,2 K
ETS-D5: ± 0,5 K
ETS-D6: ± 0,2 K
_
Set-up plate material
stainless steel 1.4301
white ceramic
stainless steel 1.4301
white ceramic
stainless steel 1.4301
Set-up plate dimensions Ø 135 mm Ø 135 mm Ø 125 mm
Dimensions (W × D × H) 160 × 246 × 90 mm 160 × 246 × 90 mm 168 × 220 × 105 mm
Weight 2 kg 2 kg 2,4 kg
Permissible ambient temperature 5 – 40 °C 5 – 40 °C 40 °C
Permissible relative moisture 80 % 80 % 80 %
Protection class acc. to DIN EN 60529 IP 21 IP 21 IP 21
Voltage 220 – 240 V 220 – 240 V 220 – 240 V
Frequency 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz
€ 449,00
€ 493,00
€ 564,00
€ 588,00
€ 343,00
TECHNICAL DATA
/// Comparison
Max. stirring quantity (H₂O) 20 l
Speed range 50 – 1.500 rpm
Heat output 1.000 W
Temperature range RT – 500 °C
Speed display LED
Max. magnetic bar (L × Ø) 30 – 80 mm
Safety circuit 100 – 650 °C
Control accuracy with sensor PT 1000 / ± 0,5K
Heating plate material ceramic
Set-up plate dimensions 180 × 180 mm
Weight 4 kg
€ 899,00
TECHNICAL DATA
/// C-MAG HS 7 control, Ident. No. 0020002694
42 43
