TECHNICAL DATA
/// Comparison
KS 130 basic | control
Ident. No. 0002980000
Ident. No. 0002980100
KS 260 basic | control
Ident. No. 0002980200
Ident. No. 0002980300
KS 501 digital
Ident. No. 0025002985
Type of movement orbital orbital orbital
Shaking diameter 4 mm 10 mm 30 mm
Permissible shaking weight
(incl. attachment)
2 kg 7,5 kg 15 kg
Motor rating input / output
45 / 10 W 45 / 10 W 70 / 19 W
Permissible ON time 100 % 100 % 100 %
Speed range 80 – 800 rpm
50 – 500 rpm |
10 – 500 rpm
0 – 300 rpm
Speed display LED line | digital LED line | digital 7 Segment LED
Timer
∞ / 5 – 50 min |
∞ / 0 – 9 h 59 min
∞ / 5 – 50 min |
∞ / 0 – 9 h 59 min
∞ / 1 – 56 min
Timer display LED line | digital LED line | digital scale
Operating mode
Timer and continuous
operation
Timer and continuous
operation
Timer and continuous
operation
Dimensions (W × D × H)
270 × 316 × 98 mm 360 × 420 × 98 mm 505 × 585 × 120 mm
Weight 8,8 kg 8,5 kg | 8,8 kg 26 kg
Permissible ambient temp. 5 – 50 °C 5 – 50 °C 5 – 50 °C
Permissible relative moisture
80 % 80 % 80 %
Protection class acc.
to DIN EN 60529
IP 21 IP 21 IP 21
Interface no | RS 232 no | RS 232 USB and RS232
Voltage
230 V 230 V 230 V
Frequency 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz
€ 1.449,00 |
€ 2.169,00
€ 2.299,00 |
€ 2.999,00
€ 4.449,00
Technical data
/// Incubator shakers
TECHNICAL DATA
/// Comparison
KS 3000 i control | ic control
Ident. No. 0003940000
Ident. No. 0003940100
KS 4000 i control | ic control
Ident. No. 0003510000
Ident. No. 0003510100
Type of movement orbital orbital
Shaking diameter 20 mm 20 mm
Permissible shaking weight (incl. attachment) 7,5 kg 20 kg
Motor rating input / output 45 / 10 W 82 / 24 W
Power input 1.120 W 1.120 W
Permissible ON time 100 % 100 %
Speed range 10 – 500 rpm 10 – 500 rpm
Speed display LED LED
Heating temperature range RT +5 – 80 °C | RT - 10 – 80 °C RT +5 – 80 °C | RT - 10 – 80 °C
Timer ∞ / 1 – 99 min ∞ / 1 – 99 min
Timer display LED LED
Time setting range 1 s – 999 h 1 s – 999 h
Operating mode Timer and continuous operation Timer and continuous operation
Heat output 1.000 W 1.000 W
Temperature display LED LED
Temp. stability (0.2 l H2O; RT 25°C, T = 37°C) ± 0,1 K ± 0,1 K
Dimensions (W × D × H) 465 × 695 × 430 mm 580 × 750 × 525 mm
Weight 35 kg | 37 kg 50 kg | 55 kg
Permissible ambient temperature 15 – 32 °C 15 – 32 °C
Permissible relative moisture 80 % 80 %
Protection class acc. to DIN EN 60529 IP 30 IP 30
Interface USB and RS232 RS 232
Voltage 230 V 230 V
Frequency 50 / 60 Hz 50 / 60 Hz
Built-in cooling coil no | yes no | yes
€ 4.999,00 |
€ 5.999,00
€ 6.049,00 |
€ 7.049,00
34 35
Shakers Shakers
