Soundmax SM-LCD710 [6/19] Installation and connection

Power Selection

1. Power adaptor: AC adapter supplies power to the television from 220V

alternating current.

2. Car adaptor: The car adaptor (please use the included device only)

allows the TV to be powered by a car battery through the vehicle's

cigarette lighter.

Installation and connection

Installation of Stand:

Insert the fixing part of the stand into the gutter of the bracket on the rear of

the unit.

Connection of power supply:

Insert the plug of the Power adaptor or Car adaptor into the power jack of the

unit. Connect the adaptor to the power source.

Earphone connection:

Connect the earphone plug to the phone jack of the unit.

Note: If earphone is applied, the sound only transmits through the earphone,

and no sound is available from the speaker of the TV set.

Connection of external antenna:

Insert one end of the external TV antenna or cable antenna cord plug to the

antenna jack of the unit.

Connection of audio-video jack:

Insert one end of the included audio-video cable into the Audio/video in jack

of the unit. Connect the other ends of the cable (yellow for video/red and

white for audio) to corresponding terminals of an external device, such as VCD

or DVD player etc.

In order to receive clearer picture

Adjust the length, angle and direction of the telescopic antenna to obtain

optimum image. Draw back the antenna from the butt end after usage.
