WiCo
Control elements of the WiCo:
Item Designation
M On/Off button: Switching the WiCo on and off
L Lock button: Disable buttons and rotary / push knobs
N Menu button: Press it once: main menu is displayed
Press it a second time: back to the working screen
B Rotary/push knob: Navigation, selecting and changing the settings in the menu
O Back button: Return to the previous menu level / reset the torque
K Gear button: Change the gear in different speed / torque ranges
Note: Can be activated only when the station is in stand-by mode.
Working screen at the time of delivery:
Explanation of symbols on the working screen:
The symbols displayed change depending on the
status and settings of the WiCo. The screen be
-
low shows the most significant symbols on the
working screen.
The start screen appears for a few seconds after
the WiCo is switched on. The device name and
the software version are displayed. After this, the
following working screen appears automatically
in the display.
Note: The wireless symbol appears only when
the stirrer (station) is switched on.
Bluetooth
®
:
This symbol means the station and the WiCo are communicating
via Bluetooth
®
.
The symbol no longer appears if no Bluetooth
®
communication is
being performed.
Lock:
This symbol means that the function of the buttons and of the
rotary knob for controlling the WiCo are locked.
The symbol no longer appears if the functions are unlocked once
again by pressing the lock button a second time.
B Operating mode:
This symbol indicates the operating mode currently selected (A,
B, C).
USB:
This symbol means the station is communicating via a USB cable.
The symbol no longer appears if no USB cable is being used for
communicating with the station.
Home:
This symbol means that the WiCo is connected to the station and
is communicating with the station via the charging contacts.
The symbol no longer appears if the WiCo is removed from the
station.
B
0
0
actual rpm
set rpm
Torque:
0.0 Ncm
Reset Torque
Back
Timer:
00:00:00
I
B
300
99:00:00
actual rpm
rated rpm
45.0 ºC
100 Ncm
Torque:
Temp.:
Timer:
00:00
PC
controlled
LIMIT 2000
I
B
M
O
N
L
K
Battery pack (rechargeable battery):
This symbol indicates the charging status of the RB 1 battery pack
within the WiCo.
The charging symbol appears if the WiCo
- is connected to a PC via a USB cable
- is connected to a station via a USB cable
- is connected to the power supply unit OS 1.0 via a USB cable
- is connected to the station via the charger contacts.
Gear ratio (speed range):
The stirrer has two different speed ranges:
Range I: low speed/high torque.
Range II: high speed/low torque.
LIMIT Speed limit:
This symbol indicates upper speed limit set for the stirrer. The setting
of the device in delivery status is the maximum permissible speed
of the stirrer.
Temperature sensor:
This symbol appears when the temperature display is active in the
display.
PC
controlled PC control symbol:
This symbol means that either the station or the WiCo is con-
nected to a computer and the stirrer is being controlled from the
computer.
PR
controlled
Program control:
This symbol means the device is controlled by user defined program.
Continuous mode:
This symbol indicates that the stirrer is in continuous mode and
indicates the direction of rotation of the stirrer.
00:00
Intermittent mode:
This symbol indicates that the stirrer is in intermittent mode.
