STARVISC 200-2.5 control // 2 / 3

Technical data STARVISC 200-2.5 control

TECHNICAL DATA

Stirring quantity max. per stirring position 100 l (H₂O)

Motor rating input 130 W

Motor rating output 84 W

Motor principle Brushless DC

Speed display TFT

Intermittent operation Yes

Viscosity max. 100 000 mPas

Output max. at stirring shaft 84 W

Permissible ON time 100 %

Stirring element fastening Chuck

Connection for ext. temperature sensor PT 1000

Plug-in coupling 10 mm (Ø)

Chuck range diameter 0.5 – 10 mm

Timer Yes/TFT

Time setting

min. 1 min

max. 6000 min

TORQUE

Measurement range 250 Ncm

Torque I max. 200 Ncm

Torque II max. 40 Ncm

Torque display Yes

Deviation of torque measurement I + II ± 2,5 Ncm

Deviation of torque measurement I + II ± 1 %

TEMPERATURE

Temperature measuring range

-10 °C min.

+350 °C max.

Temperature measurement resolution 0.1 K

Accuracy of temperature measurement

± 0.5 K + tolerance

PT 1000 (DIN IEC 751

Class A)

Limit deviation temperature sensor ≤ ± (0.15 + 0.002xITI) K

Temperature display Yes

SPEED

Speed range I: Speed (at 50/60 Hz) 6 – 400 rpm

Speed range II: Speed (at 50/60 Hz) 30 – 2000 rpm

Speed control Stepless

Setting accuracy speed ± 1 rpm

Deviation of speed measurement

n > 300 rpm

± 1 %

Deviation of speed measurement

n < 300 rpm

± 3 rpm

GENERAL DATA

Weight 5.9 kg

Communication distance (depends on

building) max.

150 m

Dimensions (W × H × D) 91 × 395 × 231 mm

Permissible ambient temperature 5 – 40 °C

Permissible relative humidity 80 %

Voltage 230 / 100 – 115 / 100V

Power input 130 W

Protection class according to DIN EN

60529

IP 40

Housing material

Alu-cast coating/

thermoplastic polymer
