IKA ROTAVISC // 2 / 3
Technical data ROTAVISC
TECHNICAL DATA
Viscosity accuracy 1 %
Viscosity repeatibility 0.2 %
Display TFT
Motor rating output 4.8 W
Working temperature
Min.: -100 °C
Max.: +300 °C
Speed 0.01 – 200 rpm
Setting accuracy speed 0.01 rpm
Temperature measurement resolution 0.1 K
Connection for ext. temperature sensor PT 100
Graph function
Calibration option
Touch function
Overload protection
Yes
Yes
Yes
Yes
Operating mode
Timer and continuous
operation
Attachment on stand Extension arm
Interfaces
USB, RS 232,
Analog output
GENERAL DATA
Weight 7.1 kg
Dimensions (W × H × D) 351 x 629 x 372 mm
Permissible ambient temperature 5 – 40 °C
Permissible relative humidity 50 %
Voltage 100 – 240 V
Frequency 50/60 Hz
Power input
24 W,
Standby: 0.06 W
Protection class according to DIN EN
60529
IP 40
DIFFERENT MODELS ROTAVISC
ROTAVISC lo-vi
Viscosity measuring range 1 – 6 000 000 mPas
ROTAVISC me-vi
Viscosity measuring range 100 – 40 000 000 mPas
ROTAVISC hi-vi I
Viscosity measuring range 200 – 80 000 000 mPas
ROTAVISC hi-vi II
Viscosity measuring range 800 – 320 000 000 mPas
