Commissioning

MS 4 MS 7 MS 10 HS 4 HS 7 HS 10 HP 4 HP 7 HP 10

Commissioning

Put device switch (A) in the OFF position.

Plug in mains cable (G).

Once connected to the power supply the device is in “stand-by” mode.

The right decimal point on the display (C) is lit.

Stirring

Put device switch (A) in the ON position.

Any set values are retained when device is switched off and even after

the device is disconnected from the power!

Set the engine speed with the operating button (E) on the right.

Heating

Put device switch (A) in the ON position.

Any set values are retained when device is switched off and even after

the device is disconnected from the power!

Set the target temperature for the heating plate using operating button

(D) [for VHP (E)].

The set value is indicated on the display (C). If energy is being supplied

to the heating plate, the red LED (B) lights up.

In the stir and stand-by modes,

flashes on the display after the

heat has been switched off for as long as the temperature of the set-up

surface exceeds 50°C.

Contact thermome-

ter connection

Put device switch (A) in the OFF position, unplug contact

plug.

Safety contact thermometer acc. to DIN 12878 class 2 con-

nected with jack (H).

Put device switch (A) in the ON position.

Beware the instruction manual of the contact thermometer.

Notice: Display (C) also indicates the target temperature of

the heating plate when the contact thermometer is connec-

ted.
