IKA ICC basic eco 18 0008035000 [19/37] Cooling

- 20 °C

+ 20 °C- 30 °C

RC 2 basic

RC 2 control | RC 5 basic and control

Cooling

/// Compact cooling power of 1,400 watts

IKA is expanding its product offering of highly ecient recirculating chillers by two

new devices. With the RC 5 basic and control, there are now two devices available

with a cooling power of 1,400 W, complementing the line by extremely compact

and powerful chillers.

Think smart – not only save valuable drinking water, but also energy and lower your

operating costs.

RC 2 basic

Recirculating chiller

RC 5 basic

Recirculating chiller

RC 2 control

Recirculating chiller

RC 5 control

Recirculating chiller

Temperature control productsTemperature control products
