ICC basic | control

ICC eco Package*

basic | control

ICC pro Package**

basic | control

Working temperature range RT + 10 °C to + 150 °C RT + 10 °C to + 100 °C RT + 10 °C to + 150 °C

Temperature stability ± 0.02 K | ± 0.01 K ± 0.02 K | ± 0.01 K ± 0.02 K | ± 0.01 K

Heating power 2,000 W 2,000 W 2,000 W

Cooling power – – –

Pump power pressure side 0.3 bar 0.3 bar 0.3 bar

Pump power suction side 0.2 bar 0.2 bar 0.2 bar

Max. ﬂow rate 18 l/min 18 l/min 18 l/min

External tempering no | yes no | yes no | yes

Solenoid valve control no no no

Applications › Compact immersion

circulator primarily for

internal applications.

› Usable in different bath

vessels.

› For tempering diverse

samples, e.g. for

analysis, material

and food testing.

› Heating bath circulator for internal or

simple external applications.

› For tempering various samples, e.g. in test tubes

with precise-ﬁtting IKA immersion racks.

› With pump connection set as well as suitable for

tempering small analytical devices or reaction systems.

IC basic | control

IC pro Package**

basic | control HBC 5 basic | control HBC 10 basic | control

+ 20 °C to + 250 °C RT + 10 °C to + 250 °C RT + 10 °C to + 250 °C RT +10 °C to + 250 °C

± 0.02 K | ± 0.01 K ± 0.02 K | ± 0.01 K ± 0.02 K | ± 0.01 K ± 0.02 K | ± 0.01 K

2,500 W 2,500 W 2,500 W 2,500 W

– – – –

0.61 bar 0.61 bar 0.61 bar 0.61 bar

0.45 bar 0.45 bar 0.45 bar 0.45 bar

31 l / min 31 l/min 31 l/min 31 l/min

yes yes yes yes

no | yes no | yes no | yes no | yes

› Immersion circulator for

demanding internal and

external applications.

› Can be placed in different

baths using removable

bath bridge, e.g. for

material testing in large,

open baths or for

external high-performance

tempering of analytical

devices.

› Heating bath circulator

for demanding internal

and external applications.

› IKA immersion racks can

be used for tempering

test tubes.

› Suitable for external tem-

pering of double-walled

vessels (e.g. lab reactors)

with usable volumes

greater than 3 liters.

› Powerful circulators for tempering external applications,

e.g. for tempering double-walled lab reactors or

distillation equipment.

› With IKA accessories, the HBC series circulators are

also suitable for tempering large, external, open baths.

› For the determination of temperature-dependent

material constants, e.g. viscosity or thermal conductivity

in liquid-tempered test apparatuses.

Pump connection set required for external applications. Find out more on our "Accessories" page.

* Plastic baths (eco packages) can be used at temperatures of up to + 100 °C (H

O only).

* Stainless steel baths (pro packages) can be used at temperatures of up to + 200 °C.

° At 2,000 rpm up to - 30 °C are possible.

/// = Operating temperature range (with external coolant). Advanced recirculating temperature (with external heating).

+ 0.6 bar

- 0.4 - 0.3 - 0.2 - 0.1 0 + 0.1 + 0.2 + 0.3 + 0.4 + 0.5

31 L/MIN

21 L/MIN

18 L/MIN

RELATIVE PRESSURE AND VOLUME FLOW

- 0.5 bar

ICC, RC 2

HRC 2

IC, HBC 5 | 10, CBC 5, RC 5
