Sterwins B40 [3/5] Right additional tine d25 straight blade 40x4
![Sterwins B40 [3/5] Right additional tine d25 straight blade 40x4](/views2/1551626/page3/bg3.png)
Rep
N°
Ref.
Désignation
Description
Moteur
Engine
MAv
MAr*
Qte
1 8300000101
KIT INVERSEUR MOTOB (06-2012)
KIT REVERSE GEAR BOX (06-2012)
1
2 3002184406
PLAT POTENCE GUID 40x6 EMB 6.5 VERT RAL6009
HANDLEBAR BRACKET 40x6 DRAW6.5 GREEN RAL6009
2
2 3002182706
PLAT POTENCE GUID 40x6 EMB 6.5 GRIS RAL7040
HANDLEBAR BRACKET 40x6 DRAW6.5 GREY RAL7040
2
2 3002181806
PLAT POTENCE GUID 40x6 EMB 6.5 VERT RAL6005
HANDLEBAR BRACKET 40x6 DRAW6.5 GREEN RAL6005
2
2 3002181306
PLAT POTENCE GUID 40x6 EMB 6.5 ROUGE RAL3001
HANDLEBAR BRACKET 40x6 DRAW6.5 RED RAL3001
2
2 3002180606
PLAT POTENCE GUID 40x6 EMB 6.5 GRIS (627)
HANDLEBAR BRACKET 40x6 DRAW6.5 GREY (627)
2
2 3002180506
PLAT POTENCE GUID 40x6 EMB 6.5 GRIS (8120)
HANDLEBAR BRACKET 40x6 DRAW6.5 GREY (8120)
2
2 3002180306
PLAT POTENCE GUID 40x6 EMB 6.5 NOIR RAL 9005
HANDLEBAR BRACKET 40x6 DRAW6.5 BLACK RAL 9005
2
3 3002174404
TOLE PROTECTION GAUCHE VERT RAL6009
LEFT TINE GUARD COMPACT EVO GREEN RAL6009
1
3 3002173604
TOLE PROTECTION GAUCHE VERT P381C
LEFT TINE GUARD COMPACT EVO GREEN P381C
1
3 3002173504
TOLE PROTECTION GAUCHE GRIS RAL7000
LEFT TINE GUARD COMPACT EVO Grey RAL7000
1
3 3002171304
TOLE PROTECTION GAUCHE ROUGE RAL3002
LEFT TINE GUARD COMPACT EVO RED RAL3002
1
3 3002170604
TOLE PROTECTION GAUCHE Gris (627) LEFT TINE GUARD COMPACT EVO Grey (627)
1
3 3002170504
TOLE PROTECTION GAUCHE Gris (8120) LEFT TINE GUARD COMPACT EVO Grey (8120)
1
3 3002170304
TOLE PROTECTION GAUCHE NOIR RAL9005
LEFT TINE GUARD COMPACT EVO BLACK RAL9005
1
4 3002174403
TOLE PROTECTION DROITE VERT RAL6009
RIGHT TINE GUARD COMPACT EVO GREEN RAL6009
1
4 3002173603
TOLE PROTECTION DROITE VERT P381C
RIGHT TINE GUARD COMPACT EVO GREEN P381C
1
4 3002173503
TOLE PROTECTION DROITE GRIS RAL7000
RIGHT TINE GUARD COMPACT EVO Grey RAL7000
1
4 3002171303
TOLE PROTECTION DROITE ROUGE RAL3002
RIGHT TINE GUARD COMPACT EVO RED RAL3002
1
4 3002170603
TOLE PROTECTION DROITE Gris (627)
RIGHT TINE GUARD COMPACT EVO Grey (627)
1
4 3002170503
TOLE PROTECTION DROITE Gris (8120)
RIGHT TINE GUARD COMPACT EVO Grey (8120)
1
4 3002170303
TOLE PROTECTION DROITE NOIR RAL9005
RIGHT TINE GUARD COMPACT EVO BLACK RAL9005
1
5 3002174401
CHASSIS COMPACT EVO VERT RAL6009
FRAME OF COMPACT EVO GREEN RAL6009
1
5 3002171301
CHASSIS COMPACT EVO ROUGE RAL3002
FRAME OF COMPACT EVO RED RAL3002
1
5 3002170601
CHASSIS COMPACT EVO Gris (627)
FRAME OF COMPACT EVO Gris (627)
1
5 3002170501
CHASSIS COMPACT EVO Gris (8120)
FRAME OF COMPACT EVO Grey (8120)
1
5 3002170301
CHASSIS COMPACT EVO NOIR RAL9005
FRAME OF COMPACT EVO BLACK RAL9005
1
6 3002170101
LEVIER D'EMB COMPACT EVO
PLATE FOR CLUTCH LEVER
1
7 3002114009
GUIDON DROIT COMPACT x500mm GRIS RAL9006
RIGHT HANDELBAR x 500mm GREY RAL9006
1
7 3002112709
GUIDON DROIT COMPACT x500mm GRIS RAL7040 RIGHT HANDELBAR x500mm GREY RAL7040
1
7 3002110709
GUIDON DROIT COMPACT x500mm GRIS (8201) RIGHT HANDELBAR x500mm GREY (8201)
1
7 3002110609
GUIDON DROIT COMPACT x500mm GRIS (627) RIGHT HANDELBAR x500mm GREY (627)
1
7 3002110509
GUIDON DROIT COMPACT x500mm GRIS (8120) RIGHT HANDELBAR x500mm GREY (8120)
1
7 3002110309
GUIDON DROIT COMPACT x500mm NOIR RAL9005
RIGHT HANDELBAR x500mm BLACK RAL9005
1
8 3002114008
GUIDON GAUCHE COMPACT x500mm GRIS RAL9006
LEFT HANDELBAR x500mm GREY RAL9006
1
8 3002112708
GUIDON GAUCHE COMPACT x500mm GRIS RAL7040
LEFT HANDELBAR x500mm GREY RAL7040
1
8 3002110708
GUIDON GAUCHE COMPACT x500mm GRIS (8201)
LEFT HANDELBAR x500mm GREY (8201)
1
8 3002110608
GUIDON GAUCHE COMPACT x500mm GRIS (627)
LEFT HANDELBAR x500mm GREY (627)
1
8 3002110508
GUIDON GAUCHE COMPACT x500mm GRIS (8120)
LEFT HANDELBAR x500mm GREY (8120)
1
8 3002110308
GUIDON GAUCHE COMPACT x500mm NOIR RAL9005
LEFT HANDELBAR x500mm BLACK RAL9005
1
9 3002000302
EPERON PRIMO NOIR RAL9005
SPUR FOR PRIMO BLACK RAL9005
1
10 3002000107
SUPPORT ROUE FIL DIA14 ZNCR3
TRANSPORT WHEEL SUPPORT WIRE D14 ZNCR3
1
11 3001000036
BEQUILLE + ROUE DOUBLE ARRIERE
SPUR + DOUBLE REAR WHEEL
1
12 3001000027
CART 1/5 JONC xGRIS8x /Jt Bleu/Ch Elite
Transmission, Grey flanged
1
13 0503000080
ETIQ. "NIVEAU DE BRUIT" 100 dB
STICKER NOISE LEVEL '100Db'
750 series/800 series/GX160/Lc/R180
1
13 0503000079
ETIQ. "NIVEAU DE BRUIT" 98 dB
Sticker noise lever '98Db'
EP/GC
1
13 0503000062
"ETIQ. ""NIVEAU DE BRUIT"" 93
STICKER NOISE LEVEL '93Db'
GT400/550 series/GX120
1
14 0503000077
ETIQ. "SECURITE" 31x31 MM PROTECTION AUDITIVE
SAFTY STICKER EARS PROTECTION
1
15 0503000043
ETIQ. GAZ (SS STOP)VERS PNEUM DIM 42X11
Label throttle control without stop
GX/Lc170/R180 1
15 0503000045
ETIQ. POIGNEE GAZ (AVEC STOP)
STICKER THROTTLE CONTROL STOP-MIN-MAX
1
16 0503000036
"ETIQ. ""SECURITE 5 LOGOS""Xce
STICKER SECURITY
1
17 0503000031
"ETIQ. ""MARCHE/ARRET""/SWITCH DIM 20 X 15
STICKER SWITCH ON/OFF GX
1
18 0341000037
POIGNEE PLASTIQUE DIAM 25 CB
HAND SIDE GRIP
2
19 0341000007
POULIE POLYA. xINV MECAx
TRANSMISSION PULLEY
1
20 0341000003
GALET 2 EPAULEMENTS ROUL 6200 ZZ
CLUTCH RUNNER ROUL 6200 ZZ
1
21 0340010190
EXT TOLE PROT COMPACT EVO VERT P381C
ADD. TINE GUARD GREEN P381C
2
21 0340010102
EXT TOLE PROT COMPACT EVO VERT RAL6029
ADD. TINE GUARD COMPACT EVO GREEN RAL6029
2
21 0340010099
EXTENTION TOLE PROT COMPACT EV GRIS RAL7000
ADD. TINE GUARD COMPACT EVO GREY RAL7000
2
21 0340010096
EXTENTION TOLE PROT COMPACT EV ORANGE RAL2009
ADD. TINE GUARD COMPACT EVO ORANGE RAL2009
2
21 0340010095
EXT TOLE PROT COMPACT EVO ORANGE P1375C
ADD. TINE GUARD ORANGE P1375C
2
21 0340010094
EXTENTION TOLE PROT COMPACT EV ROUGE RAL3001
ADD. TINE GUARD COMPACT EVO RED RAL3001
2
21 0340010092
EXT TOLE PROT COMPACT EVO NOIR RAL9005
ADD. TINE GUARD xBLACK RAL9005
2
21 0340010101
EXTENTION TOLE PROT COMPACT EV BLEU RAL5010
ADD. TINE GUARD COMPACT EVO BLUE RAL5010
2
22 0340010100
CAPOT COURROIE ECO+99 GRIS RAL7000
BELT COVER Grey RAL7000 COMPACT
1
22 0340010090
CAPOT COURROIE ECO+99 JAUNE P116x
Belt cover yellow P116
1
22 0340010073
CAPOT COURROIE ECO+99 ORANGE P1375C
BELT COVER ORANGE P1375c COMPACT
1
22 0340010072
CAPO COUR ECO+99 ROUGE RAL3020
BELT COVER RED RAL3020 COMPACT
1
22 0340010049
CAPOT COURROIE ECO+99 ORANGE P165x
Belt cover orange P165
1
22 0340010009
CAPOT COURROIE ECO+99 xVERT RAL6029x
BELT COVER GREEN RAL6029 COMPACT
1
22 0340010008
CAPOT COURROIE ECO+99 xROUGE RAL3001
BELT COVER RED RAL3001 COMPACT
1
22 0340010007
CAPOT COURROIE ECO+99 xORANGE RAL2009
BELT COVER ORANGE RAL2009
1
22 0340010006
CAPOT COURROIE ECO+99 xNOIRx
BELT COVER BLACK RAL9005 COMPACT
1
22 0340010006
CAPOT COURROIE ECO VERT RAL6009
ECO BELT COVER GREEN RAL6009
1
22 0340010005
CAPOT COURROIE ECO+99 xBLEU RAL5010
BELT COVER BLUE RAL5010 COMPACT
1
23 0340010071
CAPOT COURROIE MBR NOIR RAL9005
MBR BELT COVER BLACK RAL9005
1
24 0340010093
CACHE INT COMPACT EVO MAR
PLASTIC COVER PLATE COMPACT EVO (REVERSE)
MAr
1
24 0340010065
CACHE INT COMPACT xMAVx
PLASTIC COVER PLATE COMPACT
MAv
1
25 0330012006
SWITCH STOP GX
Switch engine cut-off
GX/R180
1
25 0330062001
SWITCH ON/OFF LONCIN SWITCH ON/OFF LONCIN
Lc
1
26 0330012003
GRILLE ECHAP GX120/GX160
EXHAUST GRILL GX120/GX160
1
26 0330032001
GRILLE ECHAPPEMENT EP
EXHAUST GRILL EP
1
26 0330062003
GRILLE ECHAPP LONCIN 212cc
EXHAUST GRILL LONCIN 212cc
1
26 0330082002
GRILLE ECHAPP GT400
EXHAUST GRILL GT400
1
26 0330092001
GRILLE ECHAPP RT180-3
Exhaust grill R180-3
1
27 0320010016
FRAISE ADDIT STD 40X4 GAUCHE
LEFT ADDITIONAL TINE D25 STRAIGHT BLADE (40X4)
2
28 0320010015
FRAISE ADDIT STD 40X4 DROIT
RIGHT ADDITIONAL TINE D25 STRAIGHT BLADE (40X4)
2
29 0320010014
FRAISE DEPART DEM STD 40X4 GAUCHE
LEFT TINE REMOVABLE D25 STRAIGHT BLADE (40X4)
1
30 0320010013
FRAISE DEPART DEM STD 40X4 DROIT
RIGHT TINE REMOVABLE D25 STRAIGHT BLADE (40X4)
1
31 0320010001
DISQUE D25 NOIR RAL9005
DISK D25 BLACK RAL9005
2
*MAv=Marche Avant / Forward running
MAr=Marche Arrière / Reverse running
