English
12
NX302E
Fileextensions
1. Always add a file extension “.MP3”,
“.WMA” to MP3, WMA le by using single
byte letters. If you add a file extension
other than specified or forget to add the
le extension, the le cannot be played.
2. Files without MP3/WMA data will not play.
The les will be played soundlessly if you
attempt to play files without MP3/WMA
data.
* When VBR les are played, the play time
display may differ the play location.
* When MP3/WMA les are played, a little
no sound part is caused between tunes.
Folderstructure
A storage with a folder having more than 8
hierarchical levels will be impossible.
Numberoflesorfolders
1. Up to 999 files can be recognized per
folder.
Up to 6000 les can be played.
2. Tracks are played in the order that they
were stored. (Tracks may not always be
played in the order displayed on the PC.)
3. Some noise may occur depending on
the type of encoder software used while
recording.
PlayingMP3folders
When selected for play, files and folders
(Folder Search, File Search or Folder Select)
are accessing in the order in which they were
written to the media.
As a result, the order in which they are
expected to be played may not match the
order in which they are actually played.
You may be able to set the order in which
MP3/WMA les are to be played by assigning
file names beginning with play sequence
numbers such as “01” to “99”.
For example, a medium with the following
folder/file hierarchy is subject to Folder
Search, File Search or Folder Select.
See the diagram below.
()
0
1
2
♪①
♪②
5
♪⑧
♪⑦
6
7
♪⑨
♪③
3
4
♪④
♪⑤
♪⑥
Layer1 Layer 2 Layer 3 Layer 4 Layer5
○ Root Folder
Folder
♪ File
The player will only recognize three folder
levels and does not display folders containing
other folders. In the example above, the unit
will display folders 2, 3, 5 and 7, but 1 and 6
since they do not contain others.
Playback menu
Touch the bottom half of screen to show
operation bar.
1. Show folder/le list(Browse)
2. Folder/Title/Artist/Album information
3. Play/Pause
4. Repeat play
5. Previous track
Fast reverse (long press)
6. Progress bar
7. Next track
Fast forward (long press)
8. Random play
9. Show other options
