4. OPERATIONS

The monitor and DVD player provide the video; headphones provide the audio. The unit

receives power from the power connector used for the car’s dome light, which the unit

replaces.

Opening the monitor

1. Press the release button to open the overhead monitor screen.

ON OFF DOOR

Release button

Looking up at the monitor from directly below

2. Gently swing the LCD down and adjust the angle for viewing.

150° maximum angle

Monitor open

CAUTION

The LCD opens to a maximum angle of 150 degrees. Do

not attempt to open it further.

The monitor turns on automatically when you fully open it (assuming the ignition switch

is on or in the ACC position).

Closing the monitor

Gently push the back side of the LCD until it clicks into the overhead housing. The monitor

turns off automatically when you return it to the closed position.

OHM888VD / OHM1088VD / OHM1588VD 12
