16 CZ109E/CZ109ER/CZ109EG
If an error occurs, one of the following messages is displayed.
Take the measures described below to eliminate the problem.
If an error display other than the ones described above appears, press the reset button. If the problem
persists, turn off the power and consult your dealer.
Radio section
Tuning System: PLL synthesizer tuner
Receiving Frequencies:
FM : 87.5 to 108 MHz (0.05 MHz steps)
MW : 531 to 1602 kHz (9 kHz steps)
LW : 153 to 279 kHz (3 kHz steps)
CD player section
System: Compact disc digital audio system
Frequency Response: 5 Hz to 20 kHz (± 1 dB)
Signal to Noise Ratio: 90 dB (1 kHz)
Dynamic Range: 85 dB (1 kHz)
Distortion: 0.01%
General
Output Power: 25 W
✕
4 (DIN 45324, +B=14.4V)
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable),
negative ground
Power Consumption: Less than 15 A
Speaker Impedance: 4 Ω (4 to 8 Ω allowable)
Weight:
Main unit: 1.15 kg
Dimensions:
Main unit:
178 (W) ✕ 50 (H) ✕ 155 (D) mm
Note:
• Specifications and design are subject to change
without notice for further improvement.
7. ERROR DISPLAYS
Error Display Cause Measure
CD/MP3/WMA
ERROR 2 A CD is caught inside the CD
deck and is not ejected.
This is a failure of the CD deck mechanism. Consult
your dealer.
ERROR 3 A CD cannot be played due
to scratches, etc.
Replace with a non-scratched, non-warped disc.
ERROR 6 A CD is loaded upside-down
inside the CD deck and does
not play.
Eject the disc and reload properly.
8. SPECIFICATIONS
