Clarion CZ505E [11/16] Trouble shooting
![Clarion CZ505E [11/16] Trouble shooting](/views2/1551962/page11/bgb.png)
English
12
CZ505E
Bluetooth Operations
Audio Streaming Operations
What is audio streaming?
Audio streaming is a technique for transferring
audio data such that it can be processed as a
steady and continuous stream. Users can stream
music from their external audio player to their car
stereo wirelessly and listen to the tracks through
the car’s speakers. Please consult your nearest
Clarion dealer for more information on the
product of wireless audio streaming transmitter
oered.
CAUTION
Please avoid operating your connected mobile
phone while audio streaming as this may cause
noise or choppy sound on the song playback.
Audio streaming may or may not resume after
telephone interrupt as this is dependent on mobile
phone.
System will always return to Radio mode if audio
streaming is disconnected.
Note:
Be sure to read the “Pairing” section before
proceeding.
Play / Pause a track
1. Push the [ 4 ] button to pause audio playback.
2. To resume audio playback, push the [ 4 ] knob
again.
Selecting a track
Track-up
1. Press the [
] button to move to the
beginning of the next track.
2. Each time the [
] button is pressed,
playback proceeds to another track in the
advancing direction.
Track-down
1. Press the [
] button to move to the
beginning of the previous track.
2. Each time the [
] button is pressed,
playback proceeds to previous track in the
reverse direction.
Note:
Playing order will depend on Bluetooth
audio
player. When [
] button is pressed, some
A2DP devices will restart the current track
depends on the duration of playback.
During music streaming playback, “A2DP
and HFP” will be shown on the display. When
A2DP device is disconnected,
“ DISCONNECT” will be shown on the display
and return to previously selected audio
source. Some Bluetooth
audio players may
not have play / pause synchronized with this
unit. Please make sure both device and main
unit are in the same play / pause status in BT
MUSIC mode.
Press [SRC /
] button on the panel to select
“AUX”.
AUX is just for audio content with 3.5mm Jack
connector plugged into audio-in socket on the
front panel.
AUX Input sensitivity setting
1. Press and hold the [ DISP ] button
(1 sec.).
AUX Operations
2. Press [ ] or [ ] button to select
“AUX SENS”.
3. If the output level of the connected
external audio player is “HIGH”, rotate
[VOLUME] knob and choose “MID” or
“LOW”. And if the output level is “LOW”,
choose “MID” or “HIGH”.
6. TROUBLE SHOOTING
GENERAL
Problem Cause Measure
Unit can not
power on.
Unit fuse blown. Replace with new fuse of correct rating.
Car battery fuse blown. Replace with new fuse of correct rating.
Unit can not
power on.
Nothing happens
when buttons are
pressed.
Display is not
accurate.
The microprocessor has
malfunctioned due to noise, etc.
Turn o the power and remove the DCP.
Press the [RESET] button with a thin rod.
Note:
When the [RESET] button is pressed, turn o
the ACC power.*
* When the [RESET] button is pressed,
preset radio stations, titles, etc. stored in
memory are kept.
No/low audio
output.
Improper audio output connection. Check wiring and correct.
Volume set too low. Increase volume level.
Speakers damaged. Replace speakers.
Heavily biased volume balance. Adjust the channel balance to center position.
Speaker wiring is in contact with
metal part of car.
Insulate all speaker wiring connections.
Poor sound quality
or distortion.
Non-standard disc used. Use a standard disc.
Speaker power rating does not
match unit.
Replace speakers.
Wrong connections. Check wiring and correct.
Speaker is shorted. Check wiring and correct.
Unit resets itself
when engine is o.
Incorrect connection between ACC
and Battery.
Check wiring and correct.
DISC Player
Problem Cause Measure
Disc cannot be
loaded.
Another disc is already loaded. Eject the disc before loading the new one.
There is an object installed inside
the unit.
Remove the object inside the unit.
Sound skips or is
noisy.
Compact disc is dirty. Clean the compact disc with a soft cloth.
Compact disc is heavily scratched
or warped.
Replace with a compact disc with no
scratches.
Sound is bad when
power is rst turned
on.
Condensation may form on the internal
lens when the car is parked in a humid
place.
Let dry for about 1 hour with power on.
