Clarion XC6210 [2/18] About the manual and warranty

2 XC6210/XC6410

English

Owner’s Manual

INTRODUCTION

The Clarion XC6210 (two-channel amplifier) and XC6410 (four-channel amplifier)

incorporate the following features:

• ConformalCoatedPCBoardthatresistsmold,mildewandmoisturedamage.

• Pulse-WidthModulated(PWM)MOSFETpowersupplyformaximum

 performancewithminimaldistortion.

• Remoteturn-onwith"softstart"mutingtopreventturn-on"thump".

• Variablehigh-pass/low-passelectroniccrossoverwitha12dBperoctave 

 slope(adjustablerange:50Hzto500Hz,500Hzto5kHz-x10).

• Variablebassboostcircuittoreinforcelowfrequencysignals.

• Adjustableinputgainlevelcontrolswithgroundloopisolationtominimizenoise

 anddistortion.

• 2-ohmstereostable,4-ohmbridgedstable.

• Corrosionresistantpower,speakerandRCAconnections.

• Speakerlevelinput.(High-levelspeakeroutputtoRCAinputadaptersincluded).

• Lowprofileconstructionwithnon-corrosivealuminumheatsinkforefficientheat

 dissipation.

ABOUT THE MANUAL AND WARRANTY

ThismanualdescribesthebasicrequirementstoinstalltheClarionXC6210and

XC6410amplifiers.Theinstallationofthisamplifiercanbequitecomplextoinstall.

Ifyoudonotpossesthenecessaryknowledgeandtoolstoperformthisinstallation,

pleasecontactyourlocalClarionaudiodealer.

Keepallinstructionsandsalesreceiptforfuturereferenceandwarrantyinformation.

TABLE OF CONTENTS

Description ............................................... 3

InputConnectionsandAudioControls .......................... 3

Installation ................................................ 7

MountingPrecautions....................................... 7

WiringPrecautions......................................... 7

XC6410WiringandApplications............................... 8

XC6210WiringandApplications............................... 12

AdjustingtheInputGainControl ............................... 14

SettingtheCrossover....................................... 14

SettingtheBassBoost...................................... 14

FinalSystemCheck........................................ 14

Troubleshooting............................................15

ProductSpecifications....................................... 17
