9 – Specifications
Dimensional drawings
465mm
483mm
44mm 1mm
31.8mm
11mm
280mm
19mm
433mm
•
Illustrations in this Owner’s Manual might differ in part from the actual product.
•
Specifications and external appearance could be changed without notification to improve the product.
