DA-6400 Control
6
TASCAM DA-6400 Control
i Master clock synchronization indicator
The name of the currently selected master clock appears
with the indicator.
o When synchronized with the master clock, the indicator
lights green.
o When not synchronized with the master clock, the
indicator blinks.
o Time code status
This indicator shows the time code connection status.
When the
GENERATOR MODE
item is not set to
TC
SYNC REC
on the
TC GENERATOR MODE
screen of
the DA-6400/DA-6400dp
o If correct timecode is input and recognition is normal, the
indicator lights green.
o If input timecode recognition is not normal, the indicator
does not light.
When the
GENERATOR MODE
item is set to
TC SYNC
REC
on the
TC GENERATOR MODE
screen of the
DA-6400/DA-6400dp
o If correct timecode is input and recognition is normal, the
indicator lights red.
o If input timecode recognition is not normal, the indicator
blinks red.
p Take name
This shows the name of the take currently loaded.
a Transport buttons
These have the same functions as the 8, 7, 9 [CHASE]
and 0 [SPLIT] buttons on the DA-6400/DA-6400dp itself.
(See “Front panel” in “2 – Names and Functions of Parts” of
the DA-6400/DA-6400dp Owner’s Manual.)
s Take number
This shows the number of the take being recorded or
playing back.
d Time bar
This shows the current playback position.
The appearance of this bar depends on the time counter
display mode.
Time counter
mode button
status
Meaning Bar display
ELAPSED
This shows the current
playback position within
the take.
The bar lengthens
from the left end to
the right end.
REMAIN
The bar shortens
from the left end to
the right end.
TOTAL
ELAPSED
This shows the current
playback position within
the total length of all the
takes in a folder.
(Vertical white lines
show the divisions
between takes.)
The bar lengthens
from the left end to
the right end.
TOTAL
REMAIN
The bar shortens
from the left end to
the right end.
TIMECODE
This shows the current
playback position within
the take.
The bar lengthens
from the left end to
the right end.
TC IN
This shows the contents
of the
TC INPUT
MONITOR
item on the
TC SETUP 1
page.
The bar does not
move.
(See “
0 Time Bar” in “2 – Names and Functions of Parts” of
the DA-6400/DA-6400dp Owner’s Manual.)
f m/, button
Tap these buttons to search backward or forward.
g .// button
When the TAKE/MARK button set to TAKE, tap these buttons
to skip to the previous or next take.
When the TAKE/MARK button set to MARK, tap these buttons
to skip to the previous or next mark.
h TAKE/MARK buttons
These set the functions (take/mark) of the .//
buttons when tapped.
j Panel lock
When the panel is unlocked, swipe left with two fingers to
lock the transport buttons.
When the panel is locked, swipe right with two fingers to
unlock the transport buttons.
Recording function and input monitoring
settings screen
1 Channel range buttons
Use these to select the range of channels (1-16/17-32/33-
48/49-64) that you want to set.
2 Recording function buttons
Tap these buttons to enable/disable recording. You can also
swipe to change the settings of multiple buttons at once.
3 Input monitoring buttons
Tap these buttons to enable/disable input monitoring. You
can also swipe to change the settings of multiple buttons at
once.
