TASCAM DA-6400/DA-6400dp
29
4 – Recording
Settings for IF-MA64/EX and IF-MA64/BN
cards
8
MADI INPUT STATUS
This shows the channel mode/frame frequency of the MADI
input signal.
Example: 64ch/32ch 48kHz
If there is no input signal,
no signal
is shown.
8
MADI INPUT FRAME
This shows the MADI input signal frame type (48K Frame/96K
Frame).
If there is no input signal,
no signal
is shown.
8
MADI INPUT SELECT (IF-MA64/EX only)
Set the input connector used.
Options:
COAXIAL
(default),
OPTICAL
8
MADI OUTPUT CH MODE
Set the output channel mode.
Options:
64ch/32ch
(default),
56ch/28ch
NOTE
Left of /: 1×Fs channel mode
Right of /: 2×Fs channel mode
8
2×Fs MADI OUTPUT FRAME
Set the MADI output signal frame type when the unit's sampling
frequency is 88.2/96kHz.
Options:
48K Frame
,
96K Frame
(default)
CAUTION
A MADI signal with a 88.2/96kHz sampling frequency and
48K Frame type cannot be distinguished from a 44.1/48kHz
sampling frequency MADI signal.
For this reason, a 48K Frame MADI input signal that does
not match the sampling frequency of the receiving device
cannot be received as proper audio data.
When using a 48K Frame MADI signal, always match the
sampling frequencies of the signal sending and receiving
devices.
NOTE
The signal from the IF-MA64/EX MADI COAXIAL IN
connector is output through its MADI COAXIAL THRU
connector whether the unit is on or off.
When the unit is turned on/off, however, the signal output
from the MADI COAXIAL THRU connector will be momen-
tarily disrupted.
For this reason, time turning the unit on/off carefully when
the signal output from the MADI COAXIAL THRU connector
is being used by a connected device.
Timecode synchronized recording
This unit captures the timecode from its built-in timecode
generator at the start of recording and uses it as the file start
time.
Recording duration
The table below shows maximum recording times by file format
on SSD/HDD drives of different capacities.
File format used
Media capacity
80GB 120GB 240GB 480GB
16-bit/44.1kHz/64-
channel
3h 55m 5h 53m 11h 47m 23h 35m
16-bit/48kHz/64-
channel
3h 36m 5h 24m 10h 49m 21h 40m
24-bit/44.1kHz/64-
channel
2h 36m 3h 55m 7h 51m 15h 43m
24-bit/48kHz/64-
channel
2h 24m 3h 36m 7h 13m 14h 26m
24-bit/88.2kHz/32-
channel
2h 36m 3h 55m 7h 51m 15h 43m
24-bit/96kHz/32-
channel
2h 24m 3h 36m 7h 13m 14h 26m
•
The recording times shown above are estimates. They might
differ depending on the media used.
•
The recording times shown above are not continuous
recording times, but rather they are the total possible
recording times for the media.
