Tascam SERIES 102i [10/38] Preparation

TASCAM SERIES 102i / SERIES 208i

4 - Preparation

Connecting the power

Use the included AC adapter (PS-P1220E) to connect a power

supply to the unit as shown below.

Power outlet

DC plug

PS-P1220E (included)

In order to prevent the cord from becoming disconnected

during use, wrap it around the cord holder when connecting it.

ATTENTION

Always use the AC adapter (PS-P1220E) that was shipped

with the unit. Using a different AC adapter could cause

malfunction, overheating, fire or other problems.

NOTE

The AC adapter for the unit includes 4 types of outlet plugs.

Attach the type of plug that matches the power outlet that

you are using. (see “Changing the outlet plug” on page 10)

Changing the outlet plug

NOTE

When purchased new, the included PS-P1220E AC adapter

for the unit has an outlet plug (A) already attached. There

should be no need to change the plug.

1. Move the knob (1) on the PS-P1220E AC adapter in the

direction of the arrow and remove the plug (A).

2. Select the plug that matches the AC outlet from the 3 other

types included (B, C or D).

3. Move the knob (1) in the direction of the arrow again, and

attach the plug to the AC adapter.

This completes changing the outlet plug.

After changing the outlet plug, confirm that it is not loose or

crooked and that everything is normal before plugging it into an

outlet.

ATTENTION

Do not use the adapter if there is anything abnormal about

the plug after changing it. Use when the plug is abnormal

could cause fire or electric shock. Contact the retailer where

you purchased the unit or a TEAC service center (on the back

cover) to request repair.
