TASCAM IF-DA2
11
1 Device name
This is the name of the device that can have its settings
changed in the current Device View.
2 Change device name
Edit the device name.
3 Sampling frequency
Set the sampling frequency.
4 Bit depth
Set the bit depth.
5 Latency setting
Set the latency.
Use the following guidelines to change the latency setting.
Selectable
latency value
Connected network setup guideline
1msec
There are up to 10 layers of gigabit switch
between transmitting device and receiving
device.
2msec
There are 100Mbps transmitters or receivers
connected to a Gigabit network.
5msec
Use this maximum selectable latency value
when creating a large-scale network.
CAUTION
i
Changing the name of a device will clear audio routing
settings. For this reason, we recommend changing device
names to names that are easy to identify before setting
audio routings.
i
Depending on network connection conditions, setting
the latency to a value higher than the guideline might be
necessary.
NOTE
i
Set the sampling rate and bit depth to the same values
as the other Dante devices that send and receive audio
signals. Also set the unit in which the IF-DA2 is installed to
the same values.
i
When using a switched (daisy chain) connection, which
does not use a switching hub, set the latency according to
the number of Dante devices that signals pass-through as
shown below.
8
Switched (daisy chain) connection example
Passes through 2 devices
Transmitting
device
e
1st device
e
2nd device
e
IF-DA2 or other
receiving device
Passes through 1 device
Transmitting
device
e
1st device
IF-DA2 or other
receiving device
