TASCAM US-2x2/US-4x4
13
6 – Using the Settings Panel
Opening the Settings Panel
You can use the Settings Panel to make settings for the various
functions of the unit.
Windows also has a Settings Panel, but we recommend using
the Software Mixer, which is more advanced in addition to
having the same functions. See chapter 8 for details about
settings when using the Software Mixer. (See “8 – Using the
Software Mixer (for Windows)” on page 17.)
Open the Settings Panel in the following manner.
Windows
8
Windows 10
Click the Windows Start button and select All Programs w
TASCAM w US-2x2 & US-4x4 Settings Panel.
8
Windows 8.1
Right-click the Windows Start button and select Control
Panel.
NOTE
You can also left-click the Start button to open the Start
screen. Click the button to open the Apps screen, and
select US-2x2 & US-4x4 Settings Panel under TASCAM.
8
Windows 7
Click the Windows Start button and select All Programs w
TASCAM w US-2x2 & US-4x4 Settings Panel.
Mac
•
Using the Finder, open the Applications folder and click
“TASCAM US-2x2 & US-4x4 Settings Panel” to open the
Settings Panel.
•
In the Audio Devices window of the Audio MIDI Setup
application, right-click (control-click) “US-2x2” or “US-4x4”
(or click the settings icon when the unit name is selected)
and click “Configure device…” to open the Settings Panel.
Settings Panel overview
Open the Settings Panel if you want to use the unit with a DAW
or other software for recording or other uses that require high
performance.
1
2
3
4
5
6
Windows Settings Panel screen
1
2
4
5
6
Mac Settings Panel screen
1 Status display area
This shows the current status of the software.
Item displayed Meaning
Driver Ver. (Windows)
Panel Ver. (Mac)
This is the software version.
Device This is the name of the
connected unit.
(“No Device” is shown when no
device is connected.)
Firmware Ver.
This is the firmware version used
by the connected unit.
Sample Rate This shows the sampling
frequency.
i The sampling frequency can
only be set in the Windows
version.
Use the displayed value
pull-down menu to select the
frequency (44.1, 48, 88.2 or
96 kHz).
2 Direct Monitor Settings
Input 1-2 and Input 3-4 (US-4x4 only)
Set the monitoring signal for the IN1-IN2/IN3-IN4 jacks to
“Mono” or “Stereo”.
o When set to “Mono”
Stereo signals sent to the computer remain unchanged,
but are output as mono signals from the LINE OUT
(BALANCED) and PHONES ( 1 and 2 jacks on US-4x4)
jacks.
o When set to “Stereo”
Stereo signals sent to the computer remain unchanged,
and are output as stereo signals from the LINE OUT
(BALANCED) and PHONES ( 1 and 2 jacks on US-4x4)
jacks.
