Protection and control
A full motor protection solution
Troubleshooting made easy
MS132 and MS165 feature a magnetic trip indicator. This way,
every tripping event will be distinguished, making troubleshoot-
ing a lot easier and faster.
An all-in-one solution
ABB offers protection against short-circuits, phase failures and
overload together with disconnecting functionality – all in one
single compact product.
Always an option
The MS116 and MS132 offer protection up to 32 A and a
short-circuit breaking capacity of 50 kA and 100 kA, respec-
tively – all in a 45 mm housing. They are designed for high
performance in addition to their compact size.
High performance in compact size
The main range of motor starters can cover short-circuit breaking
capacities up to 100 kA. Also, every motor starter is temperature
compensated up to 60 °C, making them more reliable.
