420 Technical data
ACH550-01 User's Manual
Air flow, 208…240 V drives
The following table lists the requirements for the cooling air flow
data for 208…240 V drives at full load in all ambient conditions
listed in Ambient conditions on page 440.
Dimensions and weights
The dimensions and mass for the ACH550 depend on the frame
size and enclosure type. If unsure of frame size, find first the
“Type” designation on the drive labels. Then look up this type
designation in section Ratings on page 395 to determine the
frame size.
Pages 426…438 show the dimensional drawings of the different
frame sizes for each degree of protection. A complete set of
dimensional drawings for ACH550 drives can be found on the
HVAC Info Guide (3AFE68338743 [English]).
Drive Heat dissipation Air flow Noise
ACH550-01- Frame size W BTU/hr m
3
/h ft
3
/min dB
04A6-2 R1 55 189 44 26 52
06A6-2 R1 73 249 44 26 52
07A5-2 R1 81 276 44 26 52
012A-2 R1 118 404 44 26 52
017A-2 R1 161 551 44 26 52
024A-2 R2 227 776 88 52 66
031A-2 R2 285 973 88 52 66
046A-2 R3 420 1434 134 79 67
059A-2 R3 536 1829 134 79 67
075A-2 R4 671 2290 280 165 75
088A-2 R4 786 2685 280 165 75
114A-2 R4 1014 3463 280 165 75
143A-2 R6 1268 4431 405 238 77
178A-2 R6 1575 5379 405 238 77
221A-2 R6 1952 6666 405 238 77
248A-2 R6 2189 7474 405 238 77
00467918.xls C
