Technical data of common DC applications 31
AC choke data
Symbols
Measured input currents and THD with CHK chokes and
ACS355
Symbols
Choke type L l
th
l
max
A A
CHK-01 6370 4.2 6.2
CHK-02 4610 7.6 11.4
CHK-03 2700 13.1 19.6
CHK-04 1475 22.0 26.3
CHK-05 1130 33.1 52.6
CHK-06 700 47.1 74.0
CHK-07 450 63.0 98.8
CHK-08 355 84.5 140.0
L AC choke’s nominal inductance
l
th
AC choke’s maximum allowed continuous current (rms) at a 55 °C ambient
temperature
l
max
AC choke's maximum allowed short time current (rms). This current is allowed for 10 s
only.
Choke type I
CHKthermal
Type ACS355 - I
2N
I
1NRMS
/I
1NPEAK
THD
CHK-01 4.2 A -03E-03A3-4 3.3 A 3.1/5.5 A 39.4%
CHK-02 7.6 A -03E-07A3-4 7.3 A 6.1/11.0 A 34.0%
CHK-03 13.1 A -03E-12A5-4 12.5 A 11.1/18.0 A 34.4%
CHK-04 22.0 A -03E-23A1-4 23.1 A 17.5/36.9 A 34.8%
CHK-05 33.1 A -03E-31A0-4 31.0 A 24.5/49.3 A 27.2%
CHK-06 47.1 A -03E-44A0-4 44.0 A 37.8/66.2 A 29.5%
I
CHKthermal
thermal continuous current of the choke
I
2N
continuous rms current. 50% overload is allowed for one minute every ten
minutes.
I
1NRMS
/
I
1NPEAK
line RMS current/line current peak value
