16-80 Fieldbus CTW 1
Range: Function:
0 * [0 - 65535 ] View the two-byte Control word (CTW)
received
from the Bus-Master. Interpretation of
the Control word depends on the Fieldbus
option installed and the Control word profile
selected in 8-10 Control Profile.
For more information, refer to the relevant
Fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 * [-200 -
200
]
View the two-byte word sent with the control
word form the Bus-Master to set the
reference value.
For more information, refer to the relevant
fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 * [0 - 65535 ] View the extended Fieldbus comm. option
status
word.
For more information, refer to the relevant
Fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 * [0 - 65535 ] View the two-byte Control word (CTW)
received
from the Bus-Master. Interpretation of
the control word depends on the Fieldbus
option installed and the Control word profile
selected in 8-10 Control Profile.
16-86 FC Port REF 1
Range: Function:
0 * [-200 -
200
]
View the two-byte Status word (STW) sent to
the Bus-Master. Interpretation of the Status
word depends on the fieldbus option installed
and the Control word profile selected in
8-10 Control Profile.
3.13.6 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range: Function:
0 * [0 - 4294967295 ] View the alarm word sent via the serial
communication
port in hex code.
16-91 Alarm Word 2
Range: Function:
0 * [0 - 4294967295 ] View the alarm word 2 sent via the
serial
communication port in hex code.
16-92 Warning Word
Range: Function:
0 * [0 - 4294967295 ] View the warning word sent via the
serial
communication port in hex code.
16-93 Warning Word 2
Range: Function:
0 * [0 - 4294967295 ] View the warning word 2 sent via the
serial
communication port in hex code.
16-94 Ext. Status Word
Range: Function:
0 * [0 - 4294967295 ] Returns the extended status word sent
via
the serial communication port in hex
code.
16-95 Ext. Status Word 2
Range: Function:
0 * [0 - 4294967295 ] Returns the extended warning word 2
sent
via the serial communication port
in hex code.
16-96 Maintenance Word
Range: Function:
0
*
[0 -
4294967295
]
Readout of the Preventive Maintenance
Word. The bits reflect the status for the
programmed Preventive Maintenance Events
in parameter group 23-1*. 13 bits represent
combinations of all the possible items:
•
Bit 0: Motor bearings
•
Bit 1: Pump bearings
•
Bit 2: Fan bearings
•
Bit 3: Valve
•
Bit 4: Pressure transmitter
•
Bit 5: Flow transmitter
•
Bit 6: Temperature transmitter
•
Bit 7: Pump seals
•
Bit 8: Fan belt
•
Bit 9: Filter
•
Bit 10: Drive cooling fan
•
Bit 11: Drive system health check
•
Bit 12: Warranty
•
Bit 13: Maintenance Text 0
•
Bit 14: Maintenance Text 1
•
Bit 15: Maintenance Text 2
•
Bit 16: Maintenance Text 3
•
Bit 17: Maintenance Text 4
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
108 MG16H102 - VLT
®
is a registered Danfoss trademark
33
