Danfoss VLT Refrigeration Drive FC-103N200 Инструкция по эксплуатации 110-250 кВт онлайн [71/77] 455211
![Danfoss VLT Refrigeration Drive FC-103N200 Инструкция по эксплуатации 110-250 кВт онлайн [71/77] 455211](/views2/1559618/page71/bg47.png)
typical control card power consumptions are included. Further options and customer load may add up to 30 W to
the losses. (Though typical only 4 W extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be
allowed for (±5%).
Specifications VLT® Refrigeration Drive 110-250 kW Operating Instructions
70 MG16F102 - VLT® is a registered Danfoss trademark
11
11
Содержание
- Operating instructions 1
- Additional resources 2
- Applying power to the frequency converter 2
- Basic operational programming 2
- Contents 2
- Control wiring connection 2
- Electrical installation 2
- Exploded views 2
- Installation 2
- Internal controller functions 2
- Introduction 2
- Local control test 2
- Mechanical installation 2
- Planning the installation site 2
- Pre installation checklist 2
- Pre start 2
- Product overview 2
- Purpose of the manual 2
- Safety 2
- Serial communication 2
- Start up and functional test 2
- Application set up examples 3
- Back up and copying parameter settings 3
- Control terminal programming examples 3
- International north american default parameter settings 3
- Introduction 3
- Local control panel 3
- Parameter menu structure 3
- Programming 3
- Programming example 3
- Restoring default settings 3
- Set up examples 3
- Status display 3
- Status message definitions table 3
- Status messages 3
- System monitoring 3
- System start up 3
- User interface 3
- Warning and alarm types 3
- Warnings and alarms 3
- Basic troubleshooting 4
- Fault messages 4
- Fuse specifications 4
- General specifications 4
- Mains supply 4
- Specifications 4
- Start up and operation 4
- Warning and alarm definitions 4
- Warning and alarm displays 4
- Discharge time 5
- High voltage 5
- Safety 5
- Unintended start 5
- Warning 5
- Exploded views 6
- Introduction 6
- Introduction vlt refrigeration drive 110 250 kw operating instructions 6
- Additional resources 7
- Internal controller functions 7
- Product overview 7
- Purpose of the manual 7
- Area title functions 8
- Introduction vlt refrigeration drive 110 250 kw operating instructions 8
- Caution 9
- Installation 9
- Caution 10
- Electrical installation 10
- General requirements 10
- Lifting 10
- Caution 11
- Equipment hazard 11
- Installation vlt refrigeration drive 110 250 kw operating instructions 11
- Rotating shafts and electrical equipment can be hazardous all electrical work must conform to national and local electrical codes it is strongly recommended that instal lation start up and maintenance be performed only by trained and qualified personnel failure to follow these guidelines could result in death or serious injury 11
- Run input power motor wiring and control wiring in three separate metallic conduits or use separated shielded cable for high frequency noise isolation failure to isolate power motor and control wiring could result in less than optimum frequency converter and associated equipment performance 11
- Warning 11
- Wiring isolation 11
- Warning 13
- Earthing grounding ip20 enclosures 14
- Earthing grounding ip21 54 enclosures 14
- Motor connection 15
- Warning 15
- Bc302 0 16
- Bc332 0 16
- Illustration 3 terminal locations d2h 16
- Illustration 3 terminal locations d3h 16
- Installation vlt refrigeration drive 110 250 kw operating instructions 16
- Mg16f102 vlt is a registered danfoss trademark 15 16
- Bc333 0 17
- Illustration 3 0 terminal locations d4h 17
- Installation vlt refrigeration drive 110 250 kw operating instructions 17
- Mg16f102 vlt is a registered danfoss trademark 17
- Ac mains input connection 18
- Motor cable 18
- Motor rotation check 18
- Access 19
- Control wiring connection 19
- Earthing grounding of screened control cables 19
- Using screened control cables 19
- Control terminal functions 20
- Control terminal types 20
- Serial communication 20
- Wiring to control terminals 20
- Installation vlt refrigeration drive 110 250 kw operating instructions 21
- Potential throughout the network particularly in instal lations with long cables to prevent impedance mismatch always use the same type of cable throughout the entire network when connecting a motor to the frequency converter always use screened motor cable 21
- Caution 22
- Pre start 22
- Start up and functional test 22
- Applying power to the frequency converter 23
- Basic operational programming 23
- Set up wizard 23
- Warning 23
- Required initial frequency converter programming 28
- Caution 29
- Caution 30
- System start up 30
- User interface 31
- Display 32
- Setting lcp display values 32
- Back up and copying parameter settings 33
- Data can also be downloaded into other frequency converters by connecting the lcp into those units and downloading the stored settings this is a quick way to program multiple units with the same settings 33
- Initialisation of the frequency converter to restore factory default settings does not change data stored in the lcp memory 33
- Navigation keys 33
- Navigation keys are used for programming functions and moving the display cursor the navigation keys also provide speed control in local hand operation three frequency converter status indicator lights are also located in this area 33
- Once stored in the lcp the data can be downloaded back into the frequency converter 33
- Operation keys 33
- Operation keys are found at the bottom of the lcp 33
- Programming data is stored internally in the frequency converter 33
- The data can be uploaded into the lcp memory as a storage back up 33
- User interface vlt refrigeration drive 110 250 kw operating instructions 33
- Caution 34
- Downloading data from the lcp 34
- Manual initialisation 34
- Recommended initialisation 34
- Restoring default settings 34
- Uploading data to the lcp 34
- Warning 34
- Introduction 35
- Programming 35
- Programming example 35
- Control terminal programming examples 36
- Changes made to default settings are stored and available for viewing in the quick menu along with any programming entered into parameters 37
- Default parameter 37
- International north american default parameter settings 37
- North american default parameter 37
- Parameter international 37
- Press quick menu 37
- Programming vlt refrigeration drive 110 250 kw operating instructions 37
- Scroll to 5 10 terminal 18 digital input press ok to access function choices the default setting start is shown 37
- Scroll to parameter group 5 1 digital inputs and press ok 37
- Scroll to q5 changes made and press ok 37
- Select q5 2 since factory setting to view all programming changes or q5 1 last 10 changes for the most recent 37
- Setting 0 03 regional settings to 0 international or 1 north america changes the default settings for some parameters table 6 lists those parameters that are effected 37
- Parameter data check 38
- Parameter menu structure 38
- Programming vlt refrigeration drive 110 250 kw operating instructions 39
- Quick menu structure 39
- Programming vlt refrigeration drive 110 250 kw operating instructions 40
- Main menu structure 41
- Mg16f102 vlt is a registered danfoss trademark 41
- Programming vlt refrigeration drive 110 250 kw operating instructions 41
- Mg16f102 vlt is a registered danfoss trademark 41 42
- Programming vlt refrigeration drive 110 250 kw operating instructions 42
- Mg16f102 vlt is a registered danfoss trademark 43
- Programming vlt refrigeration drive 110 250 kw operating instructions 43
- Mg16f102 vlt is a registered danfoss trademark 43 44
- Programming vlt refrigeration drive 110 250 kw operating instructions 44
- Application set up examples 45
- Application set up examples vlt refrigeration drive 110 250 kw operating instructions 46
- Fc 103 46
- Illustration 7 pressure control in closed loop stand alone system single fan or pump multiple fans or pumps in parallel 46
- Illustration 7 speed control using analogue reference open loop single fan or pump multiple fans or pumps in parallel 46
- Mg16f102 vlt is a registered danfoss trademark 45 46
- Application set up examples vlt refrigeration drive 110 250 kw operating instructions 47
- Compressor pack 47
- To find out which parameters are relevant run the wizard 47
- Status display 48
- Status message definitions table 48
- Status messages 48
- Operation status 49
- Status messages vlt refrigeration drive 110 250 kw operating instructions 49
- Operation status 50
- Status messages vlt refrigeration drive 110 250 kw operating instructions 50
- Alarm trip 51
- Alarm trip lock 51
- System monitoring 51
- Warning and alarm displays 51
- Warning and alarm types 51
- Warnings 51
- Warnings and alarms 51
- In addition to the text and alarm code on the frequency converter display there are three status indicator lights 52
- Warnings and alarms vlt refrigeration drive 110 250 kw operating instructions 52
- No description warning alarm trip alarm trip lock parameter reference 53
- Table 9 defines whether a warning is issued prior to an alarm and whether the alarm trips the unit or trip locks the unit 53
- Warning and alarm definitions 53
- Warnings and alarms vlt refrigeration drive 110 250 kw operating instructions 53
- No description warning alarm trip alarm trip lock parameter reference 54
- Warnings and alarms vlt refrigeration drive 110 250 kw operating instructions 54
- Fault messages 55
- Warning 57
- Alarm 32 motor phase w missing motor phase w between the frequency converter and the motor is missing 58
- Alarm 33 inrush fault too many power ups have occurred within a short time period let the unit cool to operating temperature 58
- Alarm 38 internal fault when an internal fault occurs a code number defined in the table below is displayed 58
- Check for loose or missing wiring 58
- Check that the option is properly installed 58
- Cycle power 58
- It may be necessary to contact your danfoss supplier or service department note the code number for further troubleshooting directions 58
- No text 58
- Remove power from the frequency converter and check motor phase v 58
- Remove power from the frequency converter and check motor phase w 58
- Troubleshooting 58
- Warning alarm 34 fieldbus communication fault the fieldbus on the communication option card is not working 58
- Warning alarm 36 mains failure this warning alarm is only active if the supply voltage to the frequency converter is lost and 14 10 mains failure is not set to 0 no function check the fuses to the frequency converter and mains power supply to the unit 58
- Warnings and alarms vlt refrigeration drive 110 250 kw operating instructions 58
- Basic troubleshooting 61
- Start up and operation 61
- Basic troubleshooting vlt refrigeration drive 110 250 kw operating instructions 62
- Symptom possible cause test solution 62
- Basic troubleshooting vlt refrigeration drive 110 250 kw operating instructions 63
- Symptom possible cause test solution 63
- General specifications 64
- Specifications 64
- Caution 68
- Mains supply 69
- Specifications vlt refrigeration drive 110 250 kw operating instructions 69
- American wire gauge 70
- For type of fuse see 11 fuse specifications 70
- Measured using 5 m screened motor cables at rated load and rated frequency 70
- Specifications vlt refrigeration drive 110 250 kw operating instructions 70
- The typical power loss is at nominal load conditions and expected to be within 15 tolerence relates to variety in voltage and cable conditions values are based on a typical motor efficiency eff2 eff3 border line motors with lower efficiency will also add to the power loss in the frequency converter and opposite if the switching frequency is increased comed to the default setting the power losses may rise significantly lcp and 70
- Fuse specifications 72
- Non ul compliance 72
- Protection 72
- 500 v the fuses below are suitable for use on a circuit capable of delivering 100 000 arms symmetrical with the proper fusing the drive short circuit current rating sccr is 100 000 arms 73
- Connection tightening torques 73
- Specifications vlt refrigeration drive 110 250 kw operating instructions 73
- Ul compliance 73
- When tightening all electrical connections it is very important to tighten with the correct torque too low or too high torque results in a bad electrical connection use a torque wrench to ensure correct torque always use a torque wrench to tighten the bolts 73
- Mg16f102 77
- Www danfoss com drives 77
