P132 P160 P200 P250
Typical Shaft output at 550 V [kW] 110 132 160 200
Typical Shaft output at 575 V [HP] 150 200 250 300
Typical Shaft output at 600 V [kW] 132 160 200 250
Enclosure IP21 D1 D1 D2 D2
Enclosure IP54 D1 D1 D2 D2
Enclosure IP00 D3 D3 D4 D4
Output current
Continuous
(at 550 V) [A]
162 201 253 303
Intermittent (60 s overload)
(at 550 V) [A]
178 221 278 333
Continuous
(at 575/600 V) [A]
155 192 242 290
Intermittent (60 s overload)
(at 575/600 V) [A]
171 211 266 319
Continuous KVA
(at 550 V) [KVA]
154 191 241 289
Continuous KVA
(at 575 V) [KVA]
154 191 241 289
Continuous KVA
(at 600 V) [KVA]
185 229 289 347
Continuous
(at 550 V) [A]
158 198 245 299
Continuous
(at 575 V) [A]
151 189 234 286
Continuous
(at 600 V) [A]
155 197 240 296
Max. cable size, mains motor, load share and
brake [mm
2
(AWG)]
2 x 70 (2 x 2/0) 2 x 70 (2 x 2/0)
2 x 150 (2 x 300
mcm)
2 x 150 (2 x 300
mcm)
Max. external pre-fuses [A]
1
315 350 350 400
Estimated power loss
at rated max. load [W]
4)
, 600 V
2963 3430 4051 4867
Estimated power loss
at rated max. load [W]
4)
, 600 V
3430 3612 4292 5156
Weight,
Enclosure IP21, IP54 [kg]
96 104 125 136
Weight,
Enclosure IP00 [kg]
82 91 112 123
Efficiency
4)
0.98
Output frequency 0-600 Hz
Heatsink overtemp. trip
90 °C 110 °C 110 °C 110 °C
Power card ambient trip
60 °C
Table 11.2 Mains Supply 3x525-600 V AC
1) For type of fuse see 11.3 Fuse Specifications
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within ±15% (tolerence relates to
variety in voltage and cable conditions). Values are based on a typical motor efficiency (eff2/eff3 border line).
Motors with lower efficiency will also add to the power loss in the frequency converter and opposite. If the
switching frequency is increased comed to the default setting, the power losses may rise significantly. LCP and
Specifications VLT® Refrigeration Drive 110-250 kW Operating Instructions
MG16F102 - VLT® is a registered Danfoss trademark 69
