3.4.2.2 Earthing (Grounding) IP20
Enclosures
The frequency converter can be earthed (grounded) using
conduit or shielded cable. For earthing (grounding) of the
power connections, use the dedicated earthing
(grounding) points as shown in Illustration 3.6.
130BC303.10
Illustration 3.5 Earthing (Grounding) Points for IP20 (Chassis)
Enclosures
3.4.2.3
Earthing (Grounding) IP21/54
Enclosures
The frequency converter can be earthed (grounded) using
conduit or shielded cable. For earthing (grounding) of the
power connections, use the dedicated earthing
(grounding) points as shown in Illustration 3.6.
130BC304.10
Illustration 3.6 Earthing (Grounding) for IP21/54 Enclosures.
Installation VLT® Refrigeration Drive 110-250 kW Operating Instructions
MG16F102 - VLT® is a registered Danfoss trademark 13
3
3
