FCM 300 Series
MG.03.B7.02 - VLT is a registered Danfoss trademark10
■ Product range
VLT
®
DriveMotor FCM 300 Series, 2/4 poled motors
Type
Motor
Mains supply
output
FCM 305 0.55 kW
FCM 307 0.75 kW
FCM 311 1.1 kW
FCM 315 1.5 kW
FCM 322 2.2 kW
3 phase 380-480 V
FCM 330 3.0 kW
FCM 340 4.0 kW
FCM 355 5.5 kW
FCM 375 7.5 kW
Each type in the product range is available in
different versions.
Inverter versions
Drive control:
-ST: Standard version
- SP: Version for PROFIBUS
RFI filter:
Inverter with integrated RFI filter, class A1 (industrial)
or class B1 (domestic).
Cooling:
- TEFV: Motor cooled by a shaft mounted fan (IC 411)
- FV: Motor cooled by an independent fan (IC 416)
Mounting versions
- Foot mounting (B3)
- Flange mounting (B5)
- Face mounting (B14)
- Foot + flange mounting (B35)
- Foot + face mounting (B34)
See chapter 6.
Inverter box position: Top, right side or left side.
Drainhole (+ position): None, between feet, opposite
feet, vertical drive end, vertical non-drive end, 90°
right of feet, 90° left of feet.
Brake kits: No brake, brake with or without hand-
release
Selection of FC motor
■ Ordering
Take a copy of the ordering forms on page 12. Fill in
and post or fax your order to the nearest branch
office of the Danfoss sales organisation. On the
basis of your order, the FCM 300 Series motor is
given a type code, which may look as follows:
FCM 330-P-T4-ST-S55-R1-100LT-4-1-B05-215-T-D1
This means that the FC motor ordered is a FCM 330
for three-phase mains voltage of 380-480 V (
T4) and
for process applications (
P). The inverter is a
standard version for remote control (
ST) in an IP55
enclosure (
S55) with integrated RFI filter, class A1
(
R1). The motor frame size is 100LT. The motor has
4 poles (
4) and is cooled by a shaft mounted fan (1).
The motor is for flange mounting (
B05) and the
flange size is
215 mm. The inverter box is mounted
on the top of the motor (
T) and the drainhole is
placed between feet (
D1).
If you wish to place your order by using the type
code directly, please use the codes given in
parenthesis on the left-hand side of the ordering
forms. The code sequence in the type code is
stated at the top of each part of the form (character
number).
The ordering form for the basic unit must always be
completed. When the type code is written, always
state the characters of the basic string (1-30).
Together with the order confirmation the customer
receives an 8-figure code number to be used when
reordering.
Danfoss PC software for serial communication
All FCM 300 Series units have an RS 485 port as
standard, which enables them to communicate e.g.
with a PC. A programme entitled VLT
®
Software
Dialog is available for this purpose (see chapter 9).
Ordering numbers, VLT
®
Software Dialog
VLT
®
Software Dialog 175Z0953
Incl Basic, Logging, Template, Guided tour modules in 6
languages (Danish, English, German, Italian, Spanish and
French)
Accessories for the FC motor
A Local Operation Pad (LOP) for local set point and
start/stop is available for the FC motor. The LOP is
IP 66 enclosed. A Local Control Panel (LCP 2) which
makes up a complete interface for operation,
programming and monitoring of the FC motor is also
available.
Ordering numbers, accessories
Local Operation Pad (LOP) 175N0128
Local Control Panel (LCP 2) 175N0131
Remote mounting kit (LCP 2) 175N0160
Plug kit (LCP 2) 175N0161
Cable for plug kit (LCP 2) 175N0162
Cable (direct mounting) (LCP 2)175N0165
Service plug kit (LCP 2) 175N0166
PG 16 to ½" NPT 176H9207
PG 21 to 3/4" NPT 176H9208
