Getting Acquainted with the Meter
To become familiar with the features and functions of the
meter, study the following figures and tables.
• Figure and Table 2 describe the input/output jacks.
• Figure and Table 3 describe the input functions you
get with the first five rotary switch positions.
• Figure and Table 4 describe the output functions you
get with the last two rotary switch positions.
• Figure and Table 5 describe the functions of the
pushbuttons.
• Figure and Table 6 explain what all the elements of
the display indicate.
A
mA
COM
V
1000V
30mA
FUSED
0.44A
(1A/30 sec)
FUSED
OUTPUT 0-24mA
SOURCE SIMULATE
+ +
CAT
1
2
3
4
ee001f.eps
Figure 2. Input/Output Jacks
