Vacon NXS0004-6A2L0SSS [11/12] Technical data
![Vacon NXS0004-6A2L0SSS [11/12] Technical data](/views2/1563540/page11/bgb.png)
Mains
connection
Input voltage U
in
208…240 V; 380…500 V; 500-690 V; (–10%…+10%)
Input frequency 50…60 Hz (± 10%)
Connection to mains Once per minute or less (normal case)
Motor
connection
Output voltage 0 – U
in
Continuous output current High overloadability: I
H
Low overloadability: I
L
Overloadability High: 1.5 x I
H
(1 min/10 min), Low: 1.1 x I
L
(1 min/10 min)
Max. starting current Is for 2 s every 20 s
Output frequency 0…320 Hz
Frequency resolution 0.01 Hz
Control
characteristics
Control method Frequency control U/f; Open Loop Vector Control (speed, torque)
Switching frequency 208..240V/380..500V:
500-690 V:
FR4-6: 1…16 kHz; Factory default: 10 kHz
FR7-9: 1…6 kHz; Factory default: 3.6 kHz
FR10-11: 1…6 kHz; Factory default: 3.6 kHz
FR4-11: 1…6 kHz, Factory default: 1.5 kHz
Field weakening point 8…320 Hz
Acceleration time 0.1…3000 sec
Deceleration time 0.1…3000 sec
Braking DC brake: 30% * T
N
(without brake resistor), ux braking
Ambient
conditions
Ambient operating
temperature
–10 °C (no frost)…+50 °C: I
H
(FR10-FR11: max +40 °C)
–10 °C (no frost)…+40 °C: I
L
(NXS 0520 5, NXS 0416 6 and NXS 0590 6: max +35 °C)
Storage temperature –40 °C…+70 °C
Relative humidity 0 to 95% RH, non-condensing, non-corrosive, no dripping water
Air quality:
– chemical vapours
– mechanical particles
IEC 60721-3-3, unit in operation, class 3C2
IEC 60721-3-3, unit in operation, class 3S2
Altitude 100% load capacity (no derating) up to 1000 m
1-% derating for each 100 m above 1000 m; max. 3000 m (max. 2000 m for 690 V)
Vibration
EN/IEC 60068-2-6
5...150 Hz: Displacement amplitude 1 mm (peak) at 5…15.8 Hz
(FR10-FR11: 0,25 mm (peak) at 5…31 Hz)
Max acceleration amplitude 1 G at 15.8…150 Hz (FR10 and up: 1 G at 31…150 Hz)
Shock
EN/IEC 60068-2-27
UPS Drop Test (for applicable UPS weights)
Storage and shipping: max 15 G, 11 ms (in package)
Protection rating IP21 and IP54
EMC Immunity Fulls all EMC immunity requirements
Emissions EMC level C: EN/IEC 61800-3 + A1, category C1
EMC level H: EN/IEC 61800-3, + A1 category C2
EMC level L: EN/IEC 61800-3, + A1 category C3
EMC level T: Low earth-current solution suitable for IT networks, EN61800-3 + A1, category C4
Control
connections
(OPT-A1, -A2
or OPT-A1, -A3)
Analogue input voltage 0…+10 V (–10 V…+10 V joystick control), R
i
= 200 kΩ, resolution 0.1%, accuracy ±1%
Analogue input current 0(4)…20 mA, R
i
= 250 Ω dierential, resolution 0.1%, accuracy ±1%
Digital inputs 6, positive or negative logic; 18…30 VDC
Auxiliary voltage +24 V, ±10%, max. 250 mA
Output reference voltage +10 V, +3%, max. load 10 mA
Analogue output 0(4)…20 mA; RL max. 500 Ω, resolution 10 bit, accuracy ±2%
Digital output Open collector output, 50 mA/48 V
Relay outputs 2 programmable change-over (NO/NC) relay outputs (OPT-A3: NO/NC+NO)
Switching capacity: 24 VDC/8 A, 250 VAC/8 A, 125 VDC/0.4 A. Min. switching load: 5 V/10 mA
Thermistor input (OPT-A3) Galvanically isolated, R
trip
= 4.7 kΩ
Other Safety EN/IEC 61800-5-1, CE, UL, cUL;
(see unit nameplate for more detailed approvals)
Protections Overvoltage, undervoltage, earth fault, mains supervision, motor phase supervision, overcurrent, unit over-
temperature, motor overload, motor stall, motor underload, short-circuit of +24 V and +10 V reference voltages
Technical data
11Danfoss Drives · DKDD.PB.913.A1.02
