5. Identify the Left and Right Base Covers (82, 83).

Slide the Left and Right Base Covers onto the

Left and Right Uprights (89, 90) as shown.

4. Hold the Right Upright (90) against the Base

(94). Make sure not to pinch the Upright Wire

(81).

Attach the Right Upright (90) with two 3/8" x

2 3/8" Screws (7), a 3/8" x 1 1/4" Screw (63),

a 3/8" x 1 3/4" Screw (62), and four 3/8" Star

Washers (13) as shown; do not fully tighten

the Screws yet.

Attach the Left Upright (not shown) in the

same way. Note: There are no wires on the left

side.
