en
9
Switching on and off
Fig. 2
Press the holiday button 6.
If vacation mode is switched on,
the button is lit and the refrigerator
compartment temperature 8,
no longer indicates a temperature.
Alarm functions
Door alarm
The door alarm (continuous sound)
switches on if the appliance door
is open for longer than one minute.
Close the door to switch off the
warning signal.
Temperature alarm
The temperature alarm switches on
if the freezer compartment is too warm
and the frozen food is at risk of thawing.
When the alarm button 5 is pressed,
the freezer compartment temperature
display 4 indicates for five seconds the
warmest temperature reached in the
freezer compartment.
Then this value is deleted.
The temperature display for the freezer
compartment 4 indicates the set
freezer compartment temperature without
flashing.
Henceforth the “warmest temperature”
will be redefined and saved.
The alarm may switch on without any
risk to the frozen food:
■ when the appliance is switched on,
■ when large quantities of fresh food are
placed in the appliance,
■ if the freezer compartment door is
open too long.
Note
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Switching off the alarm
Fig. 2
Press the alarm button 5 to switch off
the warning signal.
Usable capacity
Information on the usable capacity
can be found inside your appliance on
the rating plate. Fig. .
Fully utilising the freezer
volume
The maximum amount of food can be
placed in the freezer by removing
all fittings. The food can be stacked
directly on the shelves and in the bottom
of the freezer compartment.
Removing the fittings
Pull out the frozen food container all
the way, lift at the front and remove.
Fig. 3
