M420 General Flux Vector Control Inverter User Manual Trouble Shooting
17
serial
number
Fault Name
Possible Causes
Solutions
5
The DI
terminals are
disabled.
1: The parameters are set
incorrectly.
2: The external signal is incorrect.
3:Wrong location of the DI dial
switch.
4: The control board is faulty.
1:Check and reset the
parameters in group F5.
2: Re-connect the external
signal cables.
3. Wrong location of the
DI dial switch.
4: Contact the agent for
technical support.
6
The AC drive
reports
over-current
and
over-voltage
frequently
1: The motor parameters are set
improperly.
2: The acceleration/deceleration
time is improper.
3: The load fluctuates.
1:Re-set motor parameters
or re-perform the motor
auto- tuning.
2: Set proper acceleration/
deceleration time.
3: Contact the agent for
technical support.
