M420 General Flux Vector Control Inverter User Manual Function code Table
19
Function
Code
Parameter Name Setting Range Default
Property
Group F0:
Standard Function Parameters
F0-00
Drive model
Drive model: 5 digital display,
2 decimal point
53#.##
●
F0-01
0: for general purpose
1: for pump application
0: for general purpose
1: for pump application
0
●
F0-02 Rated driver current 0.1A to 3000.0A
Model
dependent
●
F0-03
Control mode
1: Sensor-less flux vector
control (SFVC).
2: Voltage/Frequency (V/F)
control.
2
★
F0-04
Running command source
selection
0: Operation keypad control
(LED off).
1: Terminal control (LED on).
2: Communication control
(LED blinking).
0
★
F0-05
Base frequency for
modification during running
0: Running frequency.
1: Set frequency.
0
★
F0-06
Main frequency source X
selection
0: UP/ DOWN setting
(non-recorded after stop).
1: UP/ DOWN setting
(retentive after stop).
2: AI1
3: AI2
4: Multi-speed.
5: Simple PLC.
6: PID
7: Communication setting.
8: Pulse setting.
1
★
F0-07
Auxiliary frequency
source Y selection
0: UP/ DOWN setting
(Speed reset after stop).
1: UP/ DOWN setting
0
★
